DMS Seals piston rod seal for sale

Company Advantages
1. The raw material used in DMS Seals is of high quality and has no any strange smell during use.
2. DMS Seals is manufactured as per the international quality norms and well-defined industry parameters.
3. The production of DMS Seals is of high efficiency with the help of advanced production equipment.
4. The product is not affected by the humid environment. All of its electric components are finely sealed inside the housing, which makes them not be damaged by the external conditions.
5. The product is safe to use. Its raw timber or log does not contain any toxic substances such as formaldehyde compared to other artificial woods.
6. This product has strong electromagnetic compatibility. It is not likely to be affected by external devices or cause intolerable electromagnetic interference to its surroundings.
7. Place this product on any mattress and sink into its body-cradling luxury and down-like comfort for a more restful night's sleep.
8. This product reduces the need for unskilled workers and allows them to do other work that requires skills, thus promoting a reasonable division of skills and responsibilities.
9. The product plays an important role in reflecting on people's personality and tastes, giving their room a classic and elegant appeal.
10. Due to its high accuracy levels, the product can improve production achievement whilst also reducing the time needed for quality control.
11. The actual operator who uses this product often encounters a situation in which manufacturing conditions and output rates are greatly improved over the past.

1. Installation Recommendation

2. Application and properties

Applicable to a wide range of pressure work and sliding high speed occasions. Standard combined seal. Low friction, strong wear resistance.

3. Standard materials

Sealing ring: filled PTFE

O-Ring: NBR / FKM





4. Working Conditions

Working  Conditions
Diameter Range	Pressure Range	Temperature Range	Speed	Medium
3 - 1600mm	0 - 35MPa	-30℃ + 200℃	1.5m/s	general hydraulic oil, water glycol hydraulic oil, oil / water emulsion type hydraulic oil.

5. Installation Dimensions

Nominal Size of Packing, and Housing dimensions				Order No.
d	D	H	L +0.2
12 14 16	18 20 22	3.0 3.0 3.0	3.2 3.2 3.2	SPNO12*18*3.2 SPNO14*20*3.2 SPNO16*22*3.2
18 20 22	24 26 31	3.0 3.0 3.8	3.2 3.2 4	SPNO18*24*3.2 SPNO20*26*3.2 SPNO22*31*4
25 28 30	34 37 39	3.8 3.8 3.8	4 4 4	SPNO25*34*4 SPNO28*37*4 SPNO30*39*4
32 36 40	41 45 49	3.8 3.8 3.8	4 4 4	SPNO32*41*4 SPNO36*45*4 SPNO40*49*4
45 50 56	54 65 71	3.8 6.3 6.3	4 6.5 6.5	SPNO45*54*4 SPNO50*65*6.5 SPNO56*71*6.5
60 63 70	75 78 85	6.3 6.3 6.3	6.5 6.5 6.5	SPNO60*75*6.5 SPNO63*78*6.5 SPNO70*85*6.5
75 80 85	90 95 100	6.3 6.3 6.3	6.5 6.5 6.5	SPNO75*90*6.5 SPNO80*95*6.5 SPNO85*100*6.5
90 95 100	105 110 115	6.3 6.3 6.3	6.5 6.5 6.5	SPNO90*105*6.5 SPNO95*110*6.5 SPNO100*115*6.5
105 110 115	120 125 130	6.3 6.3 6.3	6.5 6.5 6.5	SPNO105*120*6.5 SPNO110*125*6.5 SPNO115*130*6.5
120 125 130	135 140 145	6.3 6.3 6.3	6.5 6.5 6.5	SPNO120*135*6.5 SPNO125*140*6.5 SPNO130*145*6.5
135 140 145	150 155 160	6.3 6.3 6.3	6.5 6.5 6.5	SPNO135*150*6.5 SPNO140*155*6.5 SPNO145*160*6.5
150 160 170	170 180 190	9.8 9.8 9.8	10 10 10	SPNO150*170*10 SPNO160*180*10 SPNO170*190*10

Company Features
1. Dms Seals Technology Co.,limited, a(n) piston rod seal manufacturer, has built up an expertise in developing, manufacturing and exporting after years of solid development. Dms Seals Technology Co.,limited is known for providing high-quality . We have been extensively recognized and accepted in the industry. Established years ago in China, Dms Seals Technology Co.,limited is a market leader and specialist in the field of production. Dms Seals Technology Co.,limited was originally a small manufacturer in China and is now a leading developer in . Dms Seals Technology Co.,limited has been called as an expert in the industry, with years of experience and expertise in the manufacturing of .
2. DMS Seals promotes the development of technology to improve the quality of hydraulic jack piston seal . Equipped with a complete set of quality control technology, pneumatic cylinder rod seal can be guaranteed with good quality. Strong methods and sound quality management system guarantee the quality of pneumatic seals .
3. Respect for customers is one of the values of our company. And we have succeeded in teamwork, collaboration, and diversity with our customers. Call! Customer-orientation is our first and foremost principle. We think locally with regard to our clients' market conditions so as to produce distinctive products that appeal to local tastes. We offer high quality innovative products on a competitive basis. Our solutions can be tailored to meet the specific requirements of individual customers. Call! We have set out to increase our positive impact on the environment. We strive to ensure that we source our ingredients responsibly and sustainably.
