seal Custom nbrfkm rod seals hydraulic DMS Seal Manufacturer 1

seal Custom nbrfkm rod seals hydraulic DMS Seal Manufacturer 2

seal Custom nbrfkm rod seals hydraulic DMS Seal Manufacturer

Diameter Range:

3-1600mm

Pressure Range:

0-35MPa

Temperature Range:

-30℃+200℃

Speed:

1.5m/s

Medium:

general hydraulic oil, water glycol Hydraulic oil and water emulsion type hydraulic oil.

Inquiry

Company Advantages
1. Unmatched expertise of DMS Seal Manufacturer enables us to serve our clients with utmost accuracy than our industry competitors. DMS Seals provides professional design and production of high-grade o-ring seals
2. The adoption of hydraulic rod seals method can cause piston rod seal and satisfy production requirements. Seal we produced has applications in a wide range of fields
3. The R&D teams have the ability to design and develop seals for various of complicated working condition of sealing system. rod seals,hydraulic rod seals online can greatly improve capacity for your products.
4. DMS Seal manufacturer is a technology enterprise which specialized in the R&D and production of seals. The applications of rod seal catalogue technology in manufacturing process can pneumatic rod seals.
5. Dms Seals Technology Co.,limited has been manufacturing a series of hydraulic rod seals with improved efficiency and greater functionality. DMS Seals takes the lead in grasping the development trend of the industry

Installation Recommendation

undefined

Application and properties

The standard combination seal is suitable for a wide range of pressure work and sliding high speed occasions. Low friction, strong wear resistance.

Standard materials

Sealing ring: filled PTFE

O-Ring: NBR / FKM

Working Conditions

Working Conditions
Diameter Range	Pressure Range	Temperature Range	Speed	Medium
3-1600mm	0-35MPa	-30℃+200℃	1.5 m/s	general hydraulic oil, water glycol Hydraulic oil and water emulsion type hydraulic oil.

Installation Dimensions

Nominal Size of Packing, and Housing dimensions				Order No.
d	D	H	L +0.2	Order No.
3 4 5	6 7 8	2.3 2.3 2.3	2.5 2.5 2.5	SPNC362.5 SPNC472.5 SPNC582.5
6 7 8	9 10 11	2.3 2.3 2.3	2.5 2.5 2.5	SPNC692.5 SPNC7102.5 SPNC8112.5
9 10 10	12 13 14	2.3 2.3 3.0	2.5 2.5 3.2	SPNC9122.5 SPNC10132.5 SPNC10143.2
11 11.2 12	15 15.2 16	3.0 3.0 3.0	3.2 3.2 3.2	SPNC11153.2 SPNC11.215.23.2 SPNC12163.2
12.5 14 15	16.5 18 19	3.0 3.0 3.0	3.2 3.2 3.2	SPNC12.516.53.2 SPNC14183.2 SPNC15193.2
16 18 20	20 22 24	3.0 3.0 3.0	3.2 3.2 3.2	SPNC16203.2 SPNC18223.2 SPNC20243.2
20 21 22	24 25 26	3.0 3.0 3.0	3.2 3.2 3.2	SPNC20243.2 SPNC21253.2 SPNC22263.2
22 22.4 24	28 28.4 30	4.4 4.4 4.4	4.7 4.7 4.7	SPNC22284.7 SPNC22.428.44.7 SPNC24304.7
25 25.5 26	31 31.5 32	4.4 4.4 4.4	4.7 4.7 4.7	SPNC25314.7 SPNC25.531.54.7 SPNC26324.7
28 29 29.5	34 35 35.5	4.4 4.4 4.4	4.7 4.7 4.7	SPNC28344.7 SPNC29354.7 SPNC29.535.54.7
30 31 31.5	36 37 37.5	4.4 4.4 4.4	4.7 4.7 4.7	SPNC30364.7 SPNC31374.7 SPNC31.537.54.7
32 34 35	38 40 41	4.4 4.4 4.4	4.7 4.7 4.7	SPNC32384.7 SPNC34404.7 SPNC35414.7
35.5 36 38	41.5 42 44	4.4 4.4 4.4	4.7 4.7 4.7	SPNC35.541.54.7 SPNC36424.7 SPNC38444.7

Installation Dimensions

Company Features
1. Dms Seals Technology Co.,limited owns manufacturing facilities.
2. Dms Seals Technology Co.,limited make every effort to have hydraulic rod seals in this rod seals. Check now!

we welcome custom designs and ideas and is able to cater to the specific requirements. for more information, please visit the website or contact us directly with questions or inquiries.
