rdi O Ring Manufacturers supplier for sale

Company Advantages
1. DMS Seal Manufacturer rod seal catalogue is designed in line with user needs. DMS Seal manufacturer is a technology enterprise which specialized in the R&D and production of seals
2. Enough storage capacity in DMS Seal Manufacturer can also guarantee the special order from customers. DMS Seal manufacturer was established in 2008 and now has more than 10 years professional experience
3. Our experienced quality inspectors have carefully tested the product in all respects, such as its performance, durability, and so on, in accordance with the international standards. High-end talents and advanced technology have enabled DMS o-ring seal quality to reach the industry's leading level
4. The quality of this product is excellent, exceeding the industry standard. The R&D teams have the ability to design and develop seals for various of complicated working condition of sealing system
5. As our quality control procedures eliminate all defects, the products are 100% qualified. As a modern sealing technology company, DMS Seal manufacturer has a wealth of experience

1. Installation Recommendation

2. Application and properties

Applicable to a wide range of pressure work and sliding high speed occasions. Standard combined seal. Low friction, strong wear resistance.

3. Standard materials

Sealing ring: filled PTFE

O-Ring: NBR / FKM





4. Working Conditions

Working  Conditions
Diameter Range	Pressure Range	Temperature Range	Speed	Medium
3 - 1600mm	0 - 35MPa	-30℃ + 200℃	1.5m/s	general hydraulic oil, water glycol hydraulic oil, oil / water emulsion type hydraulic oil.

5. Installation Dimensions

Nominal Size of Packing, and Housing dimensions				Order No.
d	D	H	L +0.2
12 14 16	18 20 22	3.0 3.0 3.0	3.2 3.2 3.2	SPNO12*18*3.2 SPNO14*20*3.2 SPNO16*22*3.2
18 20 22	24 26 31	3.0 3.0 3.8	3.2 3.2 4	SPNO18*24*3.2 SPNO20*26*3.2 SPNO22*31*4
25 28 30	34 37 39	3.8 3.8 3.8	4 4 4	SPNO25*34*4 SPNO28*37*4 SPNO30*39*4
32 36 40	41 45 49	3.8 3.8 3.8	4 4 4	SPNO32*41*4 SPNO36*45*4 SPNO40*49*4
45 50 56	54 65 71	3.8 6.3 6.3	4 6.5 6.5	SPNO45*54*4 SPNO50*65*6.5 SPNO56*71*6.5
60 63 70	75 78 85	6.3 6.3 6.3	6.5 6.5 6.5	SPNO60*75*6.5 SPNO63*78*6.5 SPNO70*85*6.5
75 80 85	90 95 100	6.3 6.3 6.3	6.5 6.5 6.5	SPNO75*90*6.5 SPNO80*95*6.5 SPNO85*100*6.5
90 95 100	105 110 115	6.3 6.3 6.3	6.5 6.5 6.5	SPNO90*105*6.5 SPNO95*110*6.5 SPNO100*115*6.5
105 110 115	120 125 130	6.3 6.3 6.3	6.5 6.5 6.5	SPNO105*120*6.5 SPNO110*125*6.5 SPNO115*130*6.5
120 125 130	135 140 145	6.3 6.3 6.3	6.5 6.5 6.5	SPNO120*135*6.5 SPNO125*140*6.5 SPNO130*145*6.5
135 140 145	150 155 160	6.3 6.3 6.3	6.5 6.5 6.5	SPNO135*150*6.5 SPNO140*155*6.5 SPNO145*160*6.5
150 160 170	170 180 190	9.8 9.8 9.8	10 10 10	SPNO150*170*10 SPNO160*180*10 SPNO170*190*10

Company Features
1. After years of unremitting efforts, Dms Seals Technology Co.,limited has developed into a mature production enterprise. After years of continuous efforts, Dms Seals Technology Co.,limited has established a strong O Ring Manufacturers research & development department.
2. Dms Seals Technology Co.,limited is many companies' biggest competitor in quality and technology.
3. DMS Seal Manufacturer strengthens the technology of research and development of o-ring seal which satisfies the needs of different customers. rod seal catalogue is Dms Seals Technology Co.,limited original service idea, which fully shows its own superiority. Check now!
