pneumatic piston seals oring piston seals nbrfkm company 1

pneumatic piston seals oring piston seals nbrfkm company 2

pneumatic piston seals oring piston seals nbrfkm company

Diameter Range:

3-1600mm

Pressure Range:

0-35MPa

Temperature Range:

-30℃+120℃

Speed:

0.5m/s

Medium:

petroleum base hydraulic oil，nonflammable hydraulic oil, environmental protection hydraulic oil

Inquiry

Company Advantages
1. DMS Seals implements and optimizes its quality control systems. DMS Seal Manufacturer factory has established itself as a leading manufacturer, trader, and manufacture of pneumatic piston seals in the market.
2. DMS Seals provides professional design and production of high-grade o-ring seals. DMS Seal Manufacturer is full of vitality, energy and warrior spirit.
3. The integration of hydraulic piston seals sizes and hydraulic piston seals makes a popular piston seals among customers. DMS Seals manufacturer owns a team of professional R&D group and skilled technicians

Installation Recommendation

undefined

Application and properties

DBM/TPM is a double acting sealing and guiding element, Consisting of an elastomer, two back-up rings and two guide rings. Dynamic and static properties of the elastomer play a good sealing role, The back-up ring prevents the elastomer from being squeezed into the sealing gap, the function of the guide ring is to guide the piston in the cylinder and absorb the radial force. The sealing is mainly used for piston and hydraulic cylinder, such as bulldozers, excavators, loaders, hydraulic gates and agricultural machinery.

Standard materials

Guide ring: filled PTFE / PA

Back-up ring: TPU polymer

Elastomer: NBR

Working Conditions

Working Conditions
Diameter Range	Pressure Range	Temperature Range	Speed	Medium
3-1600mm	0-35MPa	-30℃+120℃	0.5 m/s	petroleum base hydraulic oil，nonflammable hydraulic oil, environmental protection hydraulic oil

Installation Dimensions

Cylinder Dia.	Groove Size					Order No.
DN H9	d1	L1 +0.2	d2 h9	d3 h11	L2 +0.1	Order No.
20 22 25	11 13 15	13.5 13.5 12	17 19 21	19 21 23	2.1 2.1 4	TPM201113.52.1 TPM221313.52.1 TPM251512*4
25 25 25	15 15 16	12.5 16.4 13.5	22 21.45 22	24 23.5 24	4 6.35 2.1	TPM251512.54 TPM251516.46.35 TPM251613.5*2.1
28 30 30	19 17 21	13.5 15.4 13.5	25 26.5 27	27 28.5 29	2.1 6.35 2.1	TPM281913.52.1 TPM301715.46.35 TPM302113.5*2.1
32 32 35	22 22 25	15.5 16.4 15.5	28 28.5 31	31 30.5 34	2.6 6.35 2.6	TPM322215.52.6 TPM322216.46.35 TPM352515.5*2.6
35 40 40	25 24 26	16.4 18.4 15.5	31.4 35.4 36	33.5 38.5 39	6.35 6.35 2.6	TPM352516.46.35 TPM402418.46.35 TPM402615.5*2.6
40 40 40	30 30 30	12.5 12.5 16.4	36 37 35.4	38 39 38.5	4 4 6.35	TPM403012.54 TPM403012.54 TPM403016.4*6.35
42 45 45	28 29 31	15.5 18.4 15.5	38 40.4 41	41 43.5 44	2.6 6.35 2.6	TPM422815.52.6 TPM452918.46.35 TPM453115.5*2.6
45 50 50	35 34 34	16.4 18.4 20.5	40.4 45.4 46	43.5 48.5 49	6.35 6.35 3.1	TPM453516.46.35 TPM503418.46.35 TPM503420.5*3.1
55 55 56	39 39 40	18.4 20.5 20.5	50.36 51 52	53.5 54 55	6.35 3.1 3.1	TPM553918.46.35 TPM553920.53.1 TPM564020.5*3.1
60 60 63	44 44 47	18.4 20.5 18.4	55.4 56 58.4	58.5 59 61.5	6.35 3.1 6.35	TPM604418.46.35 TPM604420.53.1 TPM634718.4*6.35
63 63 65	47 47 49	19.4 20.5 20.5	58.4 59 61	61.5 62 64	6.35 3.1 3.1	TPM634719.46.35 TPM634720.53.1 TPM654920.5*3.1
65 70 70	50 50 54	18.4 22.4 20.5	60.4 64.2 66	63.5 68.3 69	6.35 6.35 3.1	TPM655018.46.35 TPM705022.46.35 TPM705420.5*3.1

Installation Dimensions
