1. Installation Recommendation
2. Application and properties
Standard bidirectional seal, a wide range of applications. Friction resistance is very low, no crawling phenomenon, strong wear resistance, and saving installation space.
3. Standard materials
Sealing ring: filled PTFE
O-ring: NBR / FKM
4. Working Conditions
Working Conditions | ||||
Diameter Range | Pressure Range | Temperature Range | Speed | Medium |
3 - 1600mm | 0 - 35MPa | -30℃ +200℃ | 1.5 m/s | hydraulic oil, flame retardant liquid, water and others. |
| NO. | SIZE | NO. | SIZE |
| 1 | DPO20*14*3.2 | 32 | DPO135*121*6.5 |
| 2 | DPO25*19*3.2 | 33 | DPO140*126*6.5 |
| 3 | DPO30*21.5*4 | 34 | DPO150*136*6.5 |
| 4 | DPO31.5*23*4 | 35 | DPO160*146*6.5 |
| 5 | DPO32*23.5*4 | 36 | DPO170*150*10 |
| 6 | DPO35*26.5*4 | 37 | DPO180*160*10 |
| 7 | DPO35.5*27*4 | 38 | DPO190*170*10 |
| 8 | DPO40*31.5*4 | 39 | DPO200*180*10 |
| 9 | DPO45*36.5*4 | 40 | DPO180*160*10 |
| 10 | DPO50*41.5*4 | 41 | DPO190*170*10 |
| 11 | DPO53*44.5*4 | 42 | DPO200*180*10 |
| 12 | DPO55*46.5*4 | 43 | DPO210*190*10 |
| 13 | DPO56*47.5*4 | 44 | DPO220*200*10 |
| 14 | DPO60*51.5*4 | 45 | DPO224*204*10 |
| 15 | DPO63*49*6.5 | 46 | DPO230*210*10 |
| 16 | DPO65*51*6.5 | 47 | DPO240*220*10 |
| 17 | DPO70*56*6.5 | 48 | DPO250*230*10 |
| 18 | DPO71*57*6.5 | 49 | DPO260*240*10 |
| 19 | DPO75*61*6.5 | 50 | DPO270*250*10 |
| 20 | DPO80*66*6.5 | 51 | DPO280*260*10 |
| 21 | DPO85*71*6.5 | 52 | DPO290*270*10 |
| 22 | DPO90*76*6.5 | 53 | DPO300*280*10 |
| 23 | DPO95*81*6.5 | 54 | DPO310*290*10 |
| 24 | DPO100*86*6.5 | 55 | DPO320*300*10 |
| 25 | DPO105*91*6.5 | 56 | DPO340*320*10 |
| 26 | DPO110*96*6.5 | 57 | DPO350*330*10 |
| 27 | DPO112*98*6.5 | 58 | DPO360*340*10 |
| 28 | DPO115*101*6.5 | 59 | DPO375*355*10 |
| 29 | DPO120*106*6.5 | 60 | DPO380*360*10 |
| 30 | DPO125*111*6.5 | 61 | DPO400*380*10 |
| 31 | DPO130*116*6.5 |
Company Advantages
· DMS Seals hydraulic piston seals is known for combining aesthetic functionality and innovation.
· To meet customer's expectation and the industry standard, the product has to be subjected to strict quality inspection before shipment.
· With diverse features, this product suits the modern requirements of the market.
Company Features
· DMS Seals ushers the hydraulic piston seals industry for a profession in manufacturing hydraulic piston seals.
· Our company has brought together the right people (highly skilled assemblers and technicians, production engineers, quality engineers, purchasing staff and more). With these people's industry know-how, we are able to create benefits for our customers.
· Social engagement has always been an integral part of our sense of responsibility and firmly embedded in our corporate values. We will raise money and take part in some charity events.
Application of the Product
Dms Seals Technology's hydraulic piston seals can be used in different fields.
Dms Seals Technology has many years of industry experience and strong production strength. According to different needs of customers, we are able to provide customers with excellent and efficient one-stop solutions.
