DMS Seals Hydraulic Cylinder Piston Seal Types Top Brand 1
DMS Seals Hydraulic Cylinder Piston Seal Types Top Brand 2
DMS Seals Hydraulic Cylinder Piston Seal Types Top Brand 3
DMS Seals Hydraulic Cylinder Piston Seal Types Top Brand 4
DMS Seals Hydraulic Cylinder Piston Seal Types Top Brand 5
DMS Seals Hydraulic Cylinder Piston Seal Types Top Brand 6
DMS Seals Hydraulic Cylinder Piston Seal Types Top Brand 7
DMS Seals Hydraulic Cylinder Piston Seal Types Top Brand 1
DMS Seals Hydraulic Cylinder Piston Seal Types Top Brand 2
DMS Seals Hydraulic Cylinder Piston Seal Types Top Brand 3
DMS Seals Hydraulic Cylinder Piston Seal Types Top Brand 4
DMS Seals Hydraulic Cylinder Piston Seal Types Top Brand 5
DMS Seals Hydraulic Cylinder Piston Seal Types Top Brand 6
DMS Seals Hydraulic Cylinder Piston Seal Types Top Brand 7

DMS Seals Hydraulic Cylinder Piston Seal Types Top Brand

Diameter Range:
6-450mm
Pressure Range:
≤35MPA
Temperature Range:
-35~+80℃
Speed:
≤0.5m/s
Medium:
Hydraulic Oil
Inquiry

Product details of the hydraulic cylinder piston seal types


Product Introduction

hydraulic cylinder piston seal types from Dms Seals Technology Co.,limited explores the boundary between art and design. The product discloses a number of advantages, such as long-lasting stable performance, long service life, and so on. Putting customer service first has been always a focus of DMS Seals.


Product Description
bg


BS type piston rod seal is a lip seal with two sealing lips and a tight fit at the outer diameter. Due to the extra lubricant between the two lips,  dry friction and wear are greatly prevented. Improve its sealing performance.Adequate lubrication due to the pressure medium of the sealing lip quality inspection，Improved sealing performance under zero pressure.

    BS is primarily designed to seal piston rods and plungers in heavy duty applications in mobile and stationary hydraulic systems.It is the most critical seal on any type of fluid power equipment preventing leakage of fluid from within the cylinder to the outside.


Advantage

1.Good wear resistance

2.Little denaturation after compression

3.Impact and extrusion resistance

4.Adapt to harsh working conditions

5. Easy to install


Product Parameters
bg


NO.SIZENO.SIZENO.SIZENO.SIZE
1BS6*12*580BS32*42*10159BS60*80*12238BS100*130*15
2BS8*14*681BS32*45*10160BS63*71*8239BS105*113*11.5
3BS8*16*5.782BS32*47*10161BS63*73*6240BS105*120*9
4BS8*16*683BS34*45*6162BS63*73*11.8241BS105*120*10
5BS9*16*5.784BS35*43*4.7163BS63*73*12242BS105*125*12
6BS10*16*4.585BS35*43*5.7164BS63*73*13243BS105*125*15
7BS10*17*5.786BS35*43*7*165BS63*75*11.4244BS105*125*16
8BS10*18*5.787BS35*45*6166BS63*78*10245BS107*115*11.5
9BS10*18*688BS35*45*7167BS63*78*11.4246BS110*118*10.5
10BS10*18*889BS35*45*7.3168BS63.5*76.2*9.53247BS110*125*9
11BS10*20*590BS35*45*7.5169BS64*72*9.1248BS110*125*9.6
12BS10*20*691BS35*45*10170BS65*73*11.5249BS110*125*12*
13BS11.2*19.2*592BS35*50*10171BS65*75*6250BS110*125*14.5
14BS12*18*693BS36*43*7.3172BS65*75*7251BS110*130*10
15BS12*20*594BS36*46*7.3173BS65*75*12252BS110*130*12
16BS12*20*695BS36*51*10174BS65*78*10253BS110*130*14.5
17BS12.5*22.5*896BS37*47*7.3175BS65*80*9254BS115*130*9
18BS12.7*19.05*4.597BS37*47*10176BS65*85*11.4255BS115*130*10
19BS14*20*5.798BS38*48*6177BS67*77*6256BS115*130*12
20BS14*22*599BS38.1*47.63*6.35178BS68*78*12257BS115*135*12
21BS14*22*5.7100BS40*48*8179BS70*78*8258BS115*135*16
22BS14*24*7.3101BS40*50*6180BS70*80*6259BS118*126*13
23BS14*24*8102BS40*50*7181BS70*80*7260BS120*130*11.4
24BS15*25*8103BS40*50*7.3182BS70*80*10261BS120*130*14
25BS16*22*5104BS40*50*8*183BS70*80*11.5262BS120*130*17
26BS16*24*5105BS40*50*10184BS70*80*12263BS120*135*9
27BS18*24*5106BS40*52*8185BS70*83*10264BS120*135*14.5
28BS18*24*8107BS40*55*10*186BS70*85*9265BS120*140*12
29BS18*25*5108BS40*55*11.4187BS70*85*10266BS120*140*15
30BS18*25*8109BS43*53*7.3188BS70*85*11.4267BS125*133*11.5
31BS18*26*5110BS45*53*5.6189BS70*85*12.5268BS125*135*9
32BS18*28*8111BS45*55*6190BS75*85*6269BS125*135*11.4
33BS19*28*7112BS45*55*7191BS75*85*7270BS125*145*12
34BS20*26*5113BS45*55*7.3192BS75*85*11.5271BS125*145*15
35BS20*28*5114BS45*55*8193BS75*88*10272BS130*145*9
36BS20*28*5.7115BS45*55*10194BS75*90*9273BS130*145*12
37BS20*28*6116BS45*56*7195BS75*90*9.5274BS130*150*15
38BS20*28.3*5117BS45*57*9.5196BS75*90*10275BS135*143*10.5
39BS20*30*6118BS45*60*9197BS75*90*12276BS140*155*9.6
40BS20*30*7.3119BS45*60*10198BS75*95*12277BS140*160*12
41BS20*30*8120BS45*60*11.4199BS78*86*11.5278BS140*160*14.5
42BS22*28*6121BS46*56*10200BS80*90*6279BS145*155*11.4
43BS22*30*5122BS48*56*11.5201BS80*90*8280BS150*160*9
44BS22*30*5.7123BS48*58*6202BS80*90*12281BS150*160*11.4
45BS22*32*7.3124BS50*58*8203BS80*93*10282BS150*165*9
46BS22*32*8*125BS50*58*10204BS80*95*9283BS150*170*15
47BS22.4*30*5126BS50*60*6205BS80*95*10284BS160*170*10.5
48BS25*31*8127BS50*60*7206BS80*95*11.4285BS160*180*12
49BS25*32*7128BS50*60*7.3207BS80*95*12286BS160*180*18.5
50BS25*33*5129BS50*60*10208BS80*100*12287BS160*185*18.2
51BS25*33*6130BS50*63*6209BS85*93*11.5288BS167*175*11.5
52BS25*35*6131BS50*63*8210BS85*95*9289BS170*200*18
53BS25*35*7132BS50*65*9211BS85*100*9290BS171*179*13
54BS25*35*7.3133BS50*65*10212BS85*100*10291BS175*185*11.4
55BS25*35*8134BS50*65*11.4213BS85*100*12292BS176*186*12
56BS25*45*10135BS52*62*10214BS85*105*12293BS177.7*198*9.73
57BS25.4*31.75*6.3136BS53*63*6215BS90*98*11.5294BS180*188*11.5
58BS26*36*10137BS55*63*10216BS90*100*8295BS180*190*9
59BS28*34*8138BS55*65*6217BS90*100*10.5296BS180*190*11.4
60BS28*35.5*5139BS55*65*8218BS90*100*12297BS180*197*9.5
61BS28*35.5*5.7140BS55*65*10219BS90*105*9298BS180*200*12
62BS28*36*5.7141BS55*65*11.4220BS90*105*10299BS180*200*15
63BS28*36*6142BS55*65*12221BS90*105*11.4300BS190*210*12
64BS28*36*7143BS55*67*10222BS92*107*11.4301BS190*210*16
65BS28*36*10144BS55*68*10223BS95*105*11.4302BS193*201*11.5
66BS28*38*7.3145BS55*70*11.4224BS95*110*9303BS200*211*12
67BS28*40*8146BS55*70*12225BS95*110*10304BS200*220*12
68BS28*43*10147BS56*71*11.4226BS95*115*12305BS200*225*18.2
69BS30*37*6148BS60*68*13227BS97*105*13306BS209.6*226.8*9.6
70BS30*38*5.7149BS60*70*6228BS100*108*12307BS210*230*12
71BS30*38*6150BS60*70*7.5229BS100*110*9308BS210*235*18
72BS30*40*6151BS60*70*10230BS100*110*10309BS210*240*18
73BS30*40*7152BS60*71*7231BS100*110*11.4310BS220*245*16
74BS30*40*10153BS60*73*10232BS100*115*8311BS228.6*245.6*9
75BS30*45*10154BS60*75*9233BS100*115*9312BS230*250*17
76BS31.75*41.28*6.35155BS60*75*10234BS100*115*10313BS266.7*283.8*9.6
77BS32*42*6156BS60*75*11.4235BS100*115*12314BS280*310*18
78BS32*42*7157BS60*75*12236BS100*120*12315BS300*330*18
79BS32*42*7.3158BS60*75*13237BS100*120*14.5316BS450*474*24




Product Display
bg












Company Advantage

• Our company has established an elite team of high-tech talents integrating product research and development and innovation.
• Dms Seals Technology advocates to focus on customer's feelings and emphasizes humanized service. We also wholeheartedly serve for every customer with the work spirit of 'strict, professional and pragmatic' and the attitude of 'passionate, honest, and kind'.
• Dms Seals Technology enjoys a good geographic location. There are different major traffic lines crossing the city. The transportation of O-ring Seal,Oil Seal Manufacturer is strongly guaranteed by the unimpeded traffic.
Our products are of high quality and great safety. Besides, they are packed tightly and shockproof. Customers can rest assured to purchase our products and are warmly welcomed to contact us for details.

Contact us
we welcome custom designs and ideas and is able to cater to the specific requirements. for more information, please visit the website or contact us directly with questions or inquiries.
