Product details of the rubber seal ring manufacturers
Product Description
Quality and Design is the guiding principles in DMS Seals rubber seal ring manufacturers production. The performance of rubber seal ring manufacturers can be comparable to similar imported materials. The product is widely recognized and trusted by users and can meet continuously developing economic needs.
1. Installation Recommendation
2. Installation Sizes
|
Rod Diameter |
Outer Diameter |
Groove Width |
Install Chamfer |
Radius |
Radial Clearance S max. |
||
|
d f8 |
D H8 |
L+0.2 |
L1 |
R1 |
10MPa |
20MPa |
40MPa |
|
50-69.9 |
d+15.0 |
7.5 |
5.0 |
0.4 |
0.5 |
0.4 |
0.3 |
|
70-149.9 |
d+20.0 |
10.1 |
6.0 |
0.4 |
0.7 |
0.5 |
0.4 |
|
200-244.9 |
d+25.0 |
12.5 |
8.5 |
0.4 |
0.8 |
0.6 |
0.5 |
|
245-519.9 |
d+30.0 |
15.0 |
10.0 |
0.8 |
0.9 |
0.7 |
0.6 |
|
520-769.9 |
d+35.0 |
17.5 |
13.0 |
1.2 |
1.0 |
0.8 |
0.7 |
|
770-1500 |
d+40.0 |
20.0 |
15.0 |
1.2 |
1.0 |
0.8 |
0.7 |
3. Application and properties
Applied for larger diameter piston rods and heavy-duty hydraulic rod sealing system in hard working conditions. High pressure resistance, excellent resistance to gap extrusion, wear-resisting.
4. Standard materials
Sealing ring: filled PTFE
O-Ring: NBR / FKM
5. Working Conditions
|
Working Conditions |
||||
|
Diameter Range |
Pressure Range |
Temperature Range |
Speed |
Medium |
|
3 - 1600mm |
0 - 60MPa |
-30℃ +100℃ |
5 m/s |
hydraulic oil, flame retardant liquid, water, gas |
6. Installation Dimensions
|
Outer Dia. |
Groove Width |
Order No. |
|
|
d f8 |
D H8 |
L+0.2 |
|
|
50 60 70 |
65 75 85 |
7.5 7.5 7.5 |
GSJ-W50*65*7.5 GSJ-W60*75*7.5 GSJ-W70*85*7.5 |
|
75 80 100 |
95 100 120 |
10 10 10 |
GSJ-W75*95*10 GSJ-W80*100*10 GSJ-W100*120*10 |
|
110 115 120 |
130 135 140 |
10 10 10 |
GSJ-W110*130*10 GSJ-W115*135*10 GSJ-W120*140*10 |
|
130 140 145 |
150 160 165 |
10 10 10 |
GSJ-W130*150*10 GSJ-W140*160*10 GSJ-W145*165*10 |
|
150 160 170 |
170 180 190 |
10 10 10 |
GSJ-W150*170*10 GSJ-W160*180*10 GSJ-W170*190*10 |
|
175 180 200 |
195 200 220 |
10 10 10 |
GSJ-W175*195*10 GSJ-W180*200*10 GSJ-W200*220*10 |
|
230 240 250 |
255 265 275 |
12.5 12.5 12.5 |
GSJ-W230*255*12.5 GSJ-W240*265*12.5 GSJ-W250*275*12.5 |
|
260 265 270 |
285 290 295 |
12.5 12.5 12.5 |
GSJ-W260*285*12.5 GSJ-W265*290*12.5 GSJ-W270*295*12.5 |
|
280 290 300 |
305 315 325 |
12.5 12.5 12.5 |
GSJ-W280*305*12.5 GSJ-W290*315*12.5 GSJ-W300*325*12.5 |
