Bulk Nbr Gasket Price List
1. Application and properties
BRT are used to prevent the seal from being squeezed, and improve the pressure resistance of the seal. The standard cut shape is beveled. If there is no problem with the installation, a non-cut ring can also be used.
2. Standard materials
Bronze filled PTFE
3. Working Conditions
Working Conditions | ||||
Diameter Range | Pressure Range | Temperature Range | Speed | Medium |
3 - 1600mm | 0 - 60MPa | -45℃ +260℃ | 15 m/s | hydraulic oil, flame retardant liquid, water, gas |
4. Installation Dimensions
d | D | T | Order No. |
40 45 45 | 50 55 60 | 3 3 3 | BRT40*50*3 BRT45*55*3 BRT45*60*3 |
50 50 50 | 60 63 65 | 3 3 3 | BRT50*60*3 BRT50*63*3 BRT50*65*3 |
55 55 55 | 65 68 70 | 3 3 3 | BRT55*65*3 BRT55*68*3 BRT55*70*3 |
60 60 60 | 70 73 75 | 3 3 3 | BRT60*70*3 BRT60*73*3 BRT60*75*3 |
60 65 65 | 80 75 78 | 3 3 3 | BRT60*80*3 BRT65*75*3 BRT65*78*3 |
65 65 70 | 80 85 80 | 3 3 3 | BRT65*80*3 BRT65*85*3 BRT70*80*3 |
70 70 70 | 83 85 90 | 3 3 3 | BRT70*83*3 BRT70*85*3 BRT70*90*3 |
75 75 75 | 85 88 90 | 3 3 3 | BRT75*85*3 BRT75*88*3 BRT75*90*3 |
75 80 80 | 95 90 93 | 3 3 3 | BRT75*95*3 BRT80*90*3 BRT80*93*3 |
80 80 85 | 95 100 100 | 3 3 3 | BRT80*95*3 BRT80*100*3 BRT85*100*3 |
85 90 90 | 105 105 110 | 3 3 3 | BRT85*105*3 BRT90*105*3 BRT90*110*3 |
95 95 100 | 110 115 115 | 3 3 3 | BRT95*110*3 BRT95*115*3 BRT100*115*3 |
100 105 105 | 120 120 125 | 3 3 3 | BRT100*120*3 BRT105*120*3 BRT105*125*3 |
110 110 115 | 125 130 130 | 3 3 3 | BRT110*125*3 BRT110*130*3 BRT115*130*3 |
115 120 120 | 135 135 140 | 3 3 3 | BRT115*135*3 BRT120*135*3 BRT120*140*3 |
125 125 130 | 140 145 145 | 3 3 3 | BRT125*140*3 BRT125*145*3 BRT130*145*3 |
130 140 150 | 150 160 170 | 3 3 3 | BRT130*150*3 BRT140*160*3 BRT150*170*3 |
160 170 180 | 180 190 200 | 3 3 3 | BRT160*180*3 BRT170*190*3 BRT180*200*3 |
Company Advantages
· The production of DMS Seals nbr gasket follows the smooth production process and comes out with high accuracy.
· The product is guaranteed to be equipped with stable and reliable performance.
· The product is popular among the customers with high cost performance and takes a large market share.
Company Features
· Dms Seals Technology Co.,limited is an internationally renowned leading company dedicated to nbr gasket production.
· The technology for nbr gasket Dms Seals Technology Co.,limited mastered is advanced in China and even has approached internationally advanced status.
· DMS Seals helps our customers get the best value. Inquire online!
Application of the Product
The nbr gasket produced by Dms Seals Technology is widely used in field for its excellent quality.
Dms Seals Technology insists on providing customers with reasonable solutions according to their actual needs.
