o-ring seal with nbr or fkm o ring for sale DMS Seal Manufacturer1

Company Advantages
1. In terms of the design, the DMS Seal Manufacturer pneumatic rod seals is very appealing and competitive.
2. DMS Seal Manufacturer pneumatic rod seals is manufactured with high-grade components and other materials sourced from reliable vendors.
3. The good-looking appearance of DMS Seal Manufacturer pneumatic rod seals has caught attraction of more customers.
4. The design of DMS Seal Manufacturer o-ring seal is innovative oriented and meets the changing needs in the market. This design gradually attracts the eyes of customers.
5. DMS Seal Manufacturer pneumatic rod seals is manufactured using excellent materials that is more durable for use.
6. This product can be used for a long time. The use of a close combination of yarn and fabric makes this product more durable.
7. The product works stably under the reversible circuits. Its forward and reverse contactors are equipped with electric interlocks and mechanical interlocks to ensure smooth operation.
8. The product requires less repair time. It has a self-diagnostic function to detect the malfunction, hence to reduce human detection and maintenance.
9. The product is known for its durability. It is able to withstand a given number of cycles and maintain its performance after it runs for a long time.
10. Brand reputation continuous improvement has achieved by Dms Seals Technology Co.,limited.
11. Dms Seals Technology Co.,limited has absorbed the advantages of advanced o-ring seal at home and abroad.
12. We accept any special requirement for our o-ring seal.
13. Dms Seals Technology Co.,limited's fast and perfect service allows users to have the most stable and cost-effective products.
14. In the highly competitive market, Dms Seals Technology Co.,limited has always maintained a high sense of responsibility and a high level of management.

1. Installation Recommendation

2. Installation Sizes

Rod Diameter d e8	Groove Diameter D H9	Groove Width L D10	H
20-56	d+10	16	15
57-140	d+13	16	15
＞140	d+15	16	15

3. Application and properties

Suitable for tandem type internal sealing, and can be used as fluid sealing and dust sealing simultaneously. Excellent sealing effect can be achieved in case of no pressure. Easy installation, wear-resisting, anti extrusion, low friction, non stick slip phenomenon.

4. Standard materials

Sealing ring: filled PTFE

O-Ring: NBR / PU

5. Working Conditions

Working  Conditions
Diameter Range	Pressure Range	Temperature Range	Speed	Medium
3 - 1600mm	0 - 25MPa	-30℃ + 100℃	1 m/s	hydraulic oil, flame retardant liquid, water, gas

6. Installation Dimensions

d e8	D1 H9	H	L D10	e	Order No.
50 55 56	60 65 66	15 15 15	16 16 16	6 6 6	MDI50*60*15 MDI55*65*15 MDI56*66*15
60 63 65	73 76 78	15 15 15	16 16 16	7 7 7	MDI60*73*15 MDI63*76*15 MDI65*78*15
70 72 75	83 85 88	15 15 15	16 16 16	7 7 7	MDI70*83*15 MDI72*85*15 MDI75*88*15
80 85 90	93 98 103	15 15 15	16 16 16	7 7 7	MDI80*93*15 MDI85*98*15 MDI90*103*15
95 100 105	108 113 118	15 15 15	16 16 16	7 7 10	MDI95*108*15 MDI100*113*15 MDI105*118*15
110 110 115	120 123 128	15 15 15	16 16 16	10 10 10	MDI110*120*15 MDI110*123*15 MDI115*128*15
120 125 130	133 138 143	15 15 15	16 16 16	10 10 10	MDI120*133*15 MDI125*138*15 MDI130*143*15
140 150 150	153 162 165	15 15 15	16 16 16	10 10 10	MDI140*153*15 MDI150*162*15 MDI150*165*15
160 165 170	175 180 185	15 15 15	16 16 16	10 10 10	MDI160*175*15 MDI165*180*15 MDI170*185*15
180 185 190	195 200 205	15 15 15	16 16 16	10 10 10	MDI180*195*15 MDI185*200*15 MDI190*205*15

Company Features
1. Winning the market's appreciation in the R&D and manufacture sectors, Dms Seals Technology Co.,limited has been engaging in the production of pneumatic rod seals for years. Being praised for the manufacturing capability, Dms Seals Technology Co.,limited has taken superiority in the R&D, design, production, and marketing of hydraulic rod seals online . Specializing in the manufacture of hydraulic rod seals for so many years, Dms Seals Technology Co.,limited has gained an important presence in the market. Specialized in the development, design, and production of rod seal catalogue , Dms Seals Technology Co.,limited plays a reliable role in the industry. Dms Seals Technology Co.,limited has been a professional manufacturer and supplier of push rod seal in the market. We are known as credible and reputable.
2. DMS Seal Manufacturer is superior to others for making o-ring seal be of superior quality. Excellent hydraulic rod seals production depends on our cutting-edge technology. Dms Seals Technology Co.,limited continues to boost its technical and professional capacities with its rod seals products.
3. Our ambition is to win the market through our professional O Ring Manufacturers and service. Inquire now! The strong intent of DMS Seal Manufacturer is to become an international o-ring seal supplier in the future. Inquire now! The needs of our customers are the driving force behind DMS Seal Manufacturer's development. Inquire now! DMS Seal Manufacturer is one with our customers, treating your pain and success as our own. Inquire now!

o-ring seal with nbr or fkm o ring for sale DMS Seal Manufacturer

o-ring seal

Type:
