o ring kit manufacturer design for static sealing DMS Seal Manufacturer

Company Advantages
1. DMS Seal Manufacturer o ring kit manufacturer is developed under the concept of high-tech. During the R&D stage, its mechanical parts, microelectronic device, and intelligence control device are considered by the technicians.
2. DMS Seal Manufacturer metric wiper seal is well manufactured. Production stages including rapid prototypes, PCB fabrication, welding, performance testing, and surface treatment have been optimized.
3. Various indicators of DMS Seal Manufacturer metric wiper seal meet international pool accessories quality standards. It has passed the tests and is guaranteed to free of formaldehyde or other chemicals.
4. The product has strong wear resistance and is not likely to get pilling. The special finishing agents are used to endow it with softness and enhance its ability to resist friction.
5. The product features both soft cushioning for foot protection and firmer cushioning for propulsion. The materials used in the forefoot and rearfoot part vary for different protection functions.
6. This product has the advantage of strong corrosion resistance. The surface of it has been processed with special oxidization and plating technique.
7. A professional and strict qc team has been set up to further guarantee the quality of this product.
8. The product is highly praised among clients due to the above advantages and is used widely in the market currently.
9. This product has gained its good reputation for these attractive features.

1. Installation Recommendation

2. Application and properties

Double acting seals, the sealing effect is achieved by the deformation of the section of the O-Rings, and the deformation is determined by the depth of the installation groove. Under pressure, the O-ring has a large surface tension like liquid, used for static sealing more. It is only recommended for better conditions in dynamic applications. System lubrication, pressure, temperature, sealing clearance, speed, medium and surface quality of metal parts determine the service life of O-Rings. It is not recommended if the lubrication is not sufficient during rotary motion.

3. Standard materials

NBR / FKM

4. Performance parameter

	Static Seal	Dynamic Seal
Working Pressure	No support ring, up to 20MPa; With the support ring, up to 40MPa; With special support ring, up to 200MPa.	No support ring, up to 5MPa; With the support ring, higher pressure.
Movement Speed	Maximum reciprocating speed up to 0.5m / s; maximum rotation speed up to 2.0m/s.
Temperature	NBR: -30℃ - 100℃;  FKM: -20℃ - 220℃.

5. Wire Diameter Tolerance

Wire diameter of O-Ring (mm)	Tolerance (±mm)
0-1.8	0.08
1.80-2.65	0.09
2.65-3.55	0.10
3.55-5.30	0.13
5.30-7.00	0.15
7.00-8.00	0.18
8.00-10.00	0.21
10.00-12.00	0.25



6. Inner diameter tolerance

Inner Diameter d1 mm	Tolerance ±mm	Inner Diameter d1 mm	Tolerance ±mm	Inner Diameter d1 mm	Tolerance ±mm
0.70-2.50 2.50-4.50 4.50-6.30	0.13 0.14 0.15	43.70-45.00 46.00-46.20 46.20-47.50	0.42 0.43 0.44	95.00-97.50 97.50-100.00 100.00-103.00	0.83 0.84 0.87
6.30-8.50 8.50-10.00 10.00-11.20	0.16 0.17 0.18	47.50-48.70 48.70-50.00 50.00-51.50	0.45 0.46 0.47	103.00-106.00 106.00-109.00 109.00-112.00	0.89 0.91 0.93
11.20-14.00 14.00-16.00 16.00-18.00	0.19 0.20 0.21	51.50-53.00 53.00-54.50 54.50-56.00	0.48 0.50 0.51	112.00-115.00 115.00-118.00 118.00-122.00	0.95 0.97 1.00
18.00-20.00 20.00-21.20 21.20-23.60	0.22 0.23 0.24	56.00-58.00 58.00-60.00 60.00-61.50	0.52 0.54 0.55	122.00-125.00 125.00-128.00 128.00-132.00	1.03 1.05 1.08
23.60-25.00 25.00-26.50 26.50-28.00	0.25 0.26 0.28	61.50-63.00 63.00-65.00 65.00-67.00	0.56 0.58 0.59	132.00-136.00 136.00-140.00 140.00-145-00	1.10 1.13 1.17
28.00-30.00 30.00-31.50 31.50-33.50	0.29 0.31 0.32	67.00-69.00 69.00-71.00 71.00-73.00	0.61 0.63 0.64	145.00-150.00 150.00-155.00 155.00-160.00	1.20 1.24 1.27
33.50-34.50 34.50-35.50 35.50-36.50	0.33 0.34 0.35	73.00-75.00 75.00-77.50 77.50-80.00	0.66 0.67 0.69	160.00-165.00 165.00-170.00 170.00-175.00	1.31 1.34 1.38
36.50-37.50 37.50-38.70 38.70-40.00	0.36 0.37 0.38	80.00-82.50 82.50-85.00 85.00-87.50	0.71 0.73 0.75	175.00-180.00 180.00-185.00 185.00-190.00	1.41 1.44 1.48
40.00-41.20 41.20-42.50 42.50-43.70	0.39 0.40 0.41	87.50-90.00 90.00-92.50 92.50-95.00	0.77 0.79 0.81	190.00-195.00 195.00-200.00 200.00-206.00	1.51 1.55 1.59
206.00-212.00 212.00-218.00 224.00-230.00	1.63 1.71 1.75	325.00-335.00 335.00-345.00 345.00-355.00	2.43 2.49 2.56	500.00-515.00 515.00-530.00 530.00-545.00	3.54 3.63 3.72
230.00-236.00 236.00-243.00 243.00-250.00	1.79 1.83 1.88	355.00-365.00 365.00-375.00 375.00-387.00	2.62 2.68 2.76	545.00-560.00 560.00-580.00 580.00-600.00	3.81 3.93 4.05
250.00-258.00 258.00-265.00 265.00-272.00	1.93 1.98 2.02	387.00-400.00 400.00-412.00 412.00-425.00	2.84 2.91 2.99	600.00-615.00 615.00-630.00 630.00-650.00	4.13 4.22 4.34
272.00-280.00 280.00-290.00 290.00-300.00	2.08 2.14 2.21	425.00-437.00 437.00-450.00 450.00-462.00	3.07 3.15 3.22	650.00-670.00	4.46
300.00-307.00 307.00-315.00 315.00-325.00	2.25 2.30 2.37	462.00-475.00 475.00-485.00 485.00-500.00	3.30 3.37 3.45

Company Features
1. Over the years, Dms Seals Technology Co.,limited has been dedicated to the R&D, design, manufacturing, process improvement and innovation of high-performance o ring kit manufacturer. DMS Seal Manufacturer has been ranking top in O Ring Manufacturer industry. Dms Seals Technology Co.,limited stands above other o ring seal manufacturer suppliers now. Dms Seals Technology Co.,limited is an influential professional provider of o-ring seal .
2. Dms Seals Technology Co.,limited has a group of professional technician and a team of skillful workers for o ring kit manufacturer. With the core technology competitiveness, Dms Seals Technology Co.,limited takes up wide oversea market for o ring kit manufacturer. With professional production and R&D base, Dms Seals Technology Co.,limited takes a lead in development of o ring kit manufacturer. From design to production, our o ring kit manufacturer is checked by DMS Seal Manufacturer.
3. We promote our sustainable development in our business. We make sure that our use of energy, raw material, and natural resources are legal and environmentally friendly. We work to reduce our demand for energy through conservation, improving the energy efficiency of equipment and processes and reducing our demand on the power grid. We strive to continually innovate, improve, and advance manufacturing technologies and methodologies. Our goal is to provide the best results for our customers. We have a code of ethics that establishes the guidelines that must govern the ethical conduct of all our employees during their daily work, in particular regarding those issues related to the relations and interactions maintained with all stakeholders.

o ring kit manufacturer design for static sealing DMS Seal Manufacturer

o ring kit manufacturer

Type:
