New hydraulic oil seal manufacturers manufacturer for pneumatic equipment

Company Advantages
1. The design of DMS Seals hydraulic oil seal manufacturers is designed by our R&D team based on an analysis of the market situation. The design is reasonable and can maximize the overall performance for a wider application.
2. The well-designed DMS Seals makes it more special than other similar products.
3. DMS Seals is manufactured utilizing the precision machining equipment.
4. Strictly selected raw materials: DMS Seals is made from top grade raw materials which are all well-selected and then are quickly put into precision production.
5. DMS Seals is finely and expertly manufactured in a combination of abundant expertise and advanced production technology.
6. Our high standard quality management system guarantees the product meets with the international standards.
7. This product is cost-effective and the quality is exceptional.
8. The product performs well with great efficiency.
9. hydraulic oil seal manufacturers reflects the innovative features such as .
10. Its service life is highly guaranteed by the strict test procedure.
11. We have been leading the new fashion of hydraulic oil seal manufacturers industry, and have brought to every user.
12. Dms Seals Technology Co.,limited has taken a big jump in technology and service capacity in hydraulic oil seal manufacturers field.
13. Dms Seals Technology Co.,limited is a high-tech enterprise integrating research and development, production, marketing and service of hydraulic oil seal manufacturers together.
14. Dms Seals Technology Co.,limited has won the trust of its customers with stable and reliable product quality.

1. Installation Recommendation

2. Application and properties

Suitable for long stroke, a wide range of fluids and high temperature occasions. The application of heavy duty double acting piston sealing under high pressure conditions is excellent. Applicable to larger piston clearance , it has good leakage control, extrusion resistance and wear resistance in heavy duty and construction machinery cylinder piston sealing system. Good static sealing property, simple groove structure, larger extrusion clearances can be allowed, be able to work in dusty condition.

3. Standard materials

Sealing ring: filled PTFE

O-Ring: NBR / FKM

Back-up ring: POM / PA

4. Working Conditions

Working  Conditions
Diameter Range	Pressure Range	Temperature Range	Speed	Medium
50 - 350mm	0 - 50MPa	-30℃ +100℃	1.5 m/s	hydraulic oil, flame retardant liquid, water and others

5. Installation Dimensions

Nominal Size of Packing, and Housing dimensions			L+0.2	Order No.
D1	dN	H
50 55 60	36 41 46	8.5 8.5 8.5	9 9 9	SPGW50*36*8.5 SPGW55*41*8.5 SPGW60*46*8.5
63 65 70	48 50 55	10.5 10.5 10.5	11 11 11	SPGW63*48*10.5 SPGW65*50*10.5 SPGW70*55*10.5
75 80 85	60 65 70	10.5 10.5 10.5	11 11 11	SPGW75*60*10.5 SPGW80*65*10.5 SPGW85*70*10.5
90 95 100	75 80 85	10.5 10.5 12	11 11 12.5	SPGW90*75*10.5 SPGW95*80*10.5 SPGW100*85*12
105 110 115	90 95 100	12 12 12	12.5 12.5 12.5	SPGW105*90*12 SPGW110*95*12 SPGW115*100*12
120 125 130	105 102 107	12 15.5 15.5	12.5 16 16	SPGW120*105*12 SPGW125*102*15.5 SPGW130*107*15.5
135 140 145	112 117 122	15.5 15.5 15.5	16 16 16	SPGW135*112*15.5 SPGW140*117*15.5 SPGW145*122*15.5
150 155 160	127 132 137	15.5 15.5 15.5	16 16 16	SPGW150*127*15.5 SPGW155*132*15.5 SPGW160*137*15.5
165 170 180	142 147 157	15.5 15.5 15.5	16 16 16	SPGW165*142*15.5 SPGW170*147*15.5 SPGW180*157*15.5
185 190 200	162 167 177	15.5 15.5 15.5	16 16 16	SPGW185*162*15.5 SPGW190*167*15.5 SPGW200*177*15.5
210 220 225	187 197 202	15.5 15.5 17	16 16 17.5	SPGW210*187*15.5 SPGW220*197*15.5 SPGW225*202*15.5
230 240 250	207 217 222	17 17 17	17.5 17.5 17.5	SPGW230*207*15.5 SPGW240*217*15.5 SPGW250*222*17
260 270 280	232 242 252	17 17 17	17.5 17.5 17.5	SPGW260*232*17 SPGW270*242*17 SPGW280*252*17
300 320 350	272 292 322	17 17 17	17.5 17.5 17.5	SPGW300*272*17 SPGW320*292*17 SPGW350*322*17

Company Features
1. Dms Seals Technology Co.,limited has been concentrating on supplying customers with elaborate hydraulic oil seal manufacturers . Dms Seals Technology Co.,limited is known as a leading manufacturer for double acting piston cup . Dms Seals Technology Co.,limited is highly prestigious for its high quality hydraulic pump seals suppliers . Dms Seals Technology Co.,limited is a great manufacturer for the production of hydraulic piston seals suppliers .
2. In order to better ensure the ideal quality of pneumatic cylinder rod seal , DMS Seals has been continuously improving the technology. Dms Seals Technology Co.,limited respects talents, people-oriented, and brings together a group of experienced management and technical abilities. By keeping innovating the rod seal installation technology, we can stay ahead in the industry. Dms Seals Technology Co.,limited utilizes an abundance of technologies to generate premium quality solutions.
3. bonded piston seal is DMS Seals always operates. Get more info! As the driving force of DMS Seals, plays an important role in the market. Get more info! Dms Seals Technology Co.,limited will always strives for first-rate cylinder rod seal . Get more info! Dms Seals Technology Co.,limited inherits the culture of . Get more info!

New hydraulic oil seal manufacturers manufacturer for pneumatic equipment

hydraulic oil seal manufacturers

Type:
