nbrfkm rod rod seals DMS Seal Manufacturer Brand

Name: nbrfkm rod rod seals DMS Seal Manufacturer Brand
Brand: DMS Seals

Diameter Range:

3-1600mm

Pressure Range:

0-60MPa

Temperature Range:

-30℃+200℃

Speed:

15m/s

Medium:

hydraulic oil, flame retardant liquid, water, gas

Inquiry

Company Advantages
1. The newly launched products by Dms Seals Technology Co.,limited were all completed by the internationally renowned design company. DMS Seals provides professional design and production of high-grade o-ring seals
2. All relative certificates to guarantee quality will be provided by Dms Seals Technology Co.,limited. We can support OEM and ODM
3. The high pressure seals have strong wear resistance to hard conditions. You can make special adjustments on our rod seals,hydraulic rod seals.

Installation Recommendation

undefined

Application and properties

Applicable to high and low speed reciprocating motion environment, a wide range of fluids and high temperature condition. Suitable for larger gap of piston rod. Low friction, simple groove, be able to work in the medium with oil spots.

Standard materials

Sealing ring: filled PTFE

O-Ring: NBR / FKM

Working Conditions

Working Conditions
Diameter Range	Pressure Range	Temperature Range	Speed	Medium
3-1600mm	0-60MPa	-30℃+200℃	15 m/s	hydraulic oil, flame retardant liquid, water, gas

Installation Dimensions

Rod Dia.	Outer Dia.	Width	Order No.
d h9	D1 H9	L1+0.2	Order No.
40 45 50	50 55 60	4.2 4.2 4.2	GSW40504.2 GSW45554.2 GSW50604.2
50 53 55	65 63 65	6.8 4.2 4.2	GSW50656.8 GSW53634.2 GSW55654.2
55 60 60	70 70 75	6.8 4.2 6.8	GSW55706.8 GSW60704.2 GSW60756.8
63 65 65	73 75 80	4.2 4.2 6.8	GSW63734.2 GSW65754.2 GSW65806.8
67 70 70	77 80 82	4.2 4.2 6.8	GSW67774.2 GSW70804.2 GSW70856.8
75 75 80	85 90 90	4.2 6.8 4.2	GSW75854.2 GSW75906.8 GSW80904.2
80 85 90	75 100 105	6.8 6.8 6.8	GSW80956.8 GSW851006.8 GSW901056.8
95 100 106	110 115 121	6.8 6.8 6.8	GSW951106.8 GSW1001156.8 GSW1061216.8
110 115 120	125 130 135	6.8 6.8 6.8	GSW1101256.8 GSW1151306.8 GSW1201356.8
125 130 135	140 145 150	6.8 6.8 6.8	GSW1251406.8 GSW1301456.8 GSW1351506.8
140 145 150	155 160 165	6.8 6.8 6.8	GSW1401556.8 GSW1451606.8 GSW1501656.8
155 160 165	170 175 180	6.8 6.8 6.8	GSW1551706.8 GSW1601756.8 GSW1651806.8
170 175 180	185 190 200	6.8 6.8 8.1	GSW1701856.8 GSW1751906.8 GSW1802008.1

Installation Dimensions

Company Features
1. Please Contact Us! DMS Seal Manufacturer's rod seals, hydraulic rod seals, piston rod seal Have The Features Of High Efficient And Low Priced. We Are Willing To Enter Into Business Relations With Your Firm On The Basis Of Equality And Mutual Benefit.
2. The friendly cooperation with hydraulic rod seals online helps the growth of DMS Seal Manufacturer. Get info!

we welcome custom designs and ideas and is able to cater to the specific requirements. for more information, please visit the website or contact us directly with questions or inquiries.
