metric bonded seals hydraulic spring seal bonded seals manufacture

Company Advantages
1. We can support OEM and ODM. As one of the unique feature, metric bonded seals successfully makes bonded seals supplier more popular among customers. We can support OEM and ODM
2. Dms Seals Technology Co.,limited, well-known for its superior quality, will provide first-class service. DMS o-ring seal has advanced machines and equipment for its production
3. Our products mainly include rod seals, piston seals, scraper seals, rotary seals, rubber seal products and spring seals, DMS Seal Manufacturer Is An Exporter Which Handle Sorts Of bonded seals With Rich Experience.

1. Applicability

The BS/A bonded seals (automatic core-positioning) are applicable to threaded pipe fittings and plug sealing in Metric System, the Britain System and BSP. The location processing of sealing groove is not specially required, so it is ideal fittings for fast and automatic installation. Its service temperature is -30℃~100℃, working pressure less than 39.2MPa.

2. Dimensions

NO.	SIZE	D	d1	S
1	M30	39.00	33.00	2.00
2	M27	36.00	29.00	2.00
3	M26	35.00	28.40	2.00
4	M24	32.00	26.40	2.00
5	M22	30.00	24.40	2.00
6	M20	28.00	22.50	1.50
7	M18	26.00	20.40	1.50
8	M16	24.00	18.40	1.50
9	M14	22.00	16.40	1.50
10	M12	18.00	14.30	1.50
11	M10	16.00	12.40	1.50
12	M08	13.00	10.00	1.00
13	M06	10.00	8.00	1.00
14	M05	9.00	6.80	1.00
15	D2,0	73.03	63.63	2.50
16	D2,0	73.03	63.63	3.25
17	D1-3/4	69.85	58.30	3.25
18	D1-1/2	58.60	51.39	2.50
19	D1-1/2	58.60	51.39	3.25
20	D1-1/4	52.38	45.93	2.50
21	D1-1/4	52.38	45.93	3.25
22	D1,0	42.80	36.88	2.50
23	D1,0	42.80	36.88	3.25
24	D7/8	38.10	32.29	2.50
25	D3/4	34.93	28.53	2.00
26	D3/4	34.93	28.53	2.50
27	D5/8	31.75	24.97	2.50
28	D1/2	28.58	23.01	2.00
29	D1/2	28.58	23.01	2.50
30	D3/8	23.80	18.75	2.00
31	D1/4	20.57	15.21	2.00
32	D1/8	15.88	11.84	2.00

Company Features
1. Fully specialized in the R&D and production of bonded seals, Dms Seals Technology Co.,limited is globally recognized.
2. There is strict testing for quality of bonded seals catalogue to make satisfying products for customers.
3. Our bonded seals have been well sold to all over the world known as its metric bonded seals. Please contact.
