Latest o ring seal supplier price in highly aggressive chemical processing

Company Advantages
1. A lot of tests for DMS Seals will be carried out. The tests include dimension accuracy, material safety, colorfastness, wearing resistance, moisture-wicking, load-bearing capacity, etc.
2. Before delivery, DMS Seals must be strictly tested. It is tested for measurement, color, cracks, thickness, integrity, and polish degree.
3. DMS Seals is meticulously designed centering on the wearers. The body proportion, the convenience of movement and comfort level are the aspects seriously taken care of by apparel designers.
4. In the manufacture of DMS Seals ], strict safety requirements for furniture have been complied with. The product has been compulsorily tested in terms of structural stability, materials content, and toxicity, as well as other safety concerns.
5. DMS Seals has to be inspected in different aspects. These aspects are electrical properties, cut resistance, longitudinal and torsional stiffness, and biomechanical comfort.
6. This product is not likely to color fading. It has a polished protective layer that enables it to free of the influence of UV-ray and sunlight exposure.
7. This product is non-toxic and odor-free. Chemicals that could harm people and the environment are always avoided in its production.
8. It has good touch comfort properties. It has been tested in terms of mechanical & surface properties associated with the hand feel and performs well in the results.
9. This product will not easily generate mold. Its moisture resistance property contributes to allowing it not to be affected by the water that will easily react with bacteria.
10. This product has strong seam strength. It has passed seam strength testing in which the inspector will stretch along its seams and any edges or openings using a normal force.
11. The product helps in saving business owners' money in the long run. Because it can reduce the amount of wasted material and time.
12. This product is recycled and degradable, which means that consumers will no longer increase the amount of textile waste.
13. The product helps manufacturers reduce less-skillful workers while retaining the high level of operators, which eventually contributes to the overall competitiveness of the company.
14. By helping reduce the workload, this product can prevent employees from getting tired. This will finally contribute to the improvement of productivity.

1. Installation Recommendation

2. Application and properties

Double acting seals, the sealing effect is achieved by the deformation of the section of the O-Rings, and the deformation is determined by the depth of the installation groove. Under pressure, the O-ring has a large surface tension like liquid, used for static sealing more. It is only recommended for better conditions in dynamic applications. System lubrication, pressure, temperature, sealing clearance, speed, medium and surface quality of metal parts determine the service life of O-Rings. It is not recommended if the lubrication is not sufficient during rotary motion.

3. Standard materials

NBR / FKM

4. Performance parameter

	Static Seal	Dynamic Seal
Working Pressure	No support ring, up to 20MPa; With the support ring, up to 40MPa; With special support ring, up to 200MPa.	No support ring, up to 5MPa; With the support ring, higher pressure.
Movement Speed	Maximum reciprocating speed up to 0.5m / s; maximum rotation speed up to 2.0m/s.
Temperature	NBR: -30℃ - 100℃;  FKM: -20℃ - 220℃.

5. Wire Diameter Tolerance

Wire diameter of O-Ring (mm)	Tolerance (±mm)
0-1.8	0.08
1.80-2.65	0.09
2.65-3.55	0.10
3.55-5.30	0.13
5.30-7.00	0.15
7.00-8.00	0.18
8.00-10.00	0.21
10.00-12.00	0.25



6. Inner diameter tolerance

Inner Diameter d1 mm	Tolerance ±mm	Inner Diameter d1 mm	Tolerance ±mm	Inner Diameter d1 mm	Tolerance ±mm
0.70-2.50 2.50-4.50 4.50-6.30	0.13 0.14 0.15	43.70-45.00 46.00-46.20 46.20-47.50	0.42 0.43 0.44	95.00-97.50 97.50-100.00 100.00-103.00	0.83 0.84 0.87
6.30-8.50 8.50-10.00 10.00-11.20	0.16 0.17 0.18	47.50-48.70 48.70-50.00 50.00-51.50	0.45 0.46 0.47	103.00-106.00 106.00-109.00 109.00-112.00	0.89 0.91 0.93
11.20-14.00 14.00-16.00 16.00-18.00	0.19 0.20 0.21	51.50-53.00 53.00-54.50 54.50-56.00	0.48 0.50 0.51	112.00-115.00 115.00-118.00 118.00-122.00	0.95 0.97 1.00
18.00-20.00 20.00-21.20 21.20-23.60	0.22 0.23 0.24	56.00-58.00 58.00-60.00 60.00-61.50	0.52 0.54 0.55	122.00-125.00 125.00-128.00 128.00-132.00	1.03 1.05 1.08
23.60-25.00 25.00-26.50 26.50-28.00	0.25 0.26 0.28	61.50-63.00 63.00-65.00 65.00-67.00	0.56 0.58 0.59	132.00-136.00 136.00-140.00 140.00-145-00	1.10 1.13 1.17
28.00-30.00 30.00-31.50 31.50-33.50	0.29 0.31 0.32	67.00-69.00 69.00-71.00 71.00-73.00	0.61 0.63 0.64	145.00-150.00 150.00-155.00 155.00-160.00	1.20 1.24 1.27
33.50-34.50 34.50-35.50 35.50-36.50	0.33 0.34 0.35	73.00-75.00 75.00-77.50 77.50-80.00	0.66 0.67 0.69	160.00-165.00 165.00-170.00 170.00-175.00	1.31 1.34 1.38
36.50-37.50 37.50-38.70 38.70-40.00	0.36 0.37 0.38	80.00-82.50 82.50-85.00 85.00-87.50	0.71 0.73 0.75	175.00-180.00 180.00-185.00 185.00-190.00	1.41 1.44 1.48
40.00-41.20 41.20-42.50 42.50-43.70	0.39 0.40 0.41	87.50-90.00 90.00-92.50 92.50-95.00	0.77 0.79 0.81	190.00-195.00 195.00-200.00 200.00-206.00	1.51 1.55 1.59
206.00-212.00 212.00-218.00 224.00-230.00	1.63 1.71 1.75	325.00-335.00 335.00-345.00 345.00-355.00	2.43 2.49 2.56	500.00-515.00 515.00-530.00 530.00-545.00	3.54 3.63 3.72
230.00-236.00 236.00-243.00 243.00-250.00	1.79 1.83 1.88	355.00-365.00 365.00-375.00 375.00-387.00	2.62 2.68 2.76	545.00-560.00 560.00-580.00 580.00-600.00	3.81 3.93 4.05
250.00-258.00 258.00-265.00 265.00-272.00	1.93 1.98 2.02	387.00-400.00 400.00-412.00 412.00-425.00	2.84 2.91 2.99	600.00-615.00 615.00-630.00 630.00-650.00	4.13 4.22 4.34
272.00-280.00 280.00-290.00 290.00-300.00	2.08 2.14 2.21	425.00-437.00 437.00-450.00 450.00-462.00	3.07 3.15 3.22	650.00-670.00	4.46
300.00-307.00 307.00-315.00 315.00-325.00	2.25 2.30 2.37	462.00-475.00 475.00-485.00 485.00-500.00	3.30 3.37 3.45

Company Features
1. Dms Seals Technology Co.,limited is an enterprise which focuses on producingo ring seal supplier and is highly adaptable, cohesive and reputable. Mainly manufacturing rubber o rings ace hardware , Dms Seals Technology Co.,limited is highly competitive in terms of capabilities. Dms Seals Technology Co.,limited has won wide popularity for supplying high quality buy o ring kit . DMS Seals now has become an internationally famous brand in the field of manufacturing o ring hardware .
2. We have a highly skilled and experienced team of professionals. They are recruited on the basis of their ability and willingness to perform. They help the company in the maximization of production capacity. We have opened up and consolidated overseas sales channels. So far, we have accumulated our own loyal customer base in which customers are mainly from North America and Southeast Asia. Our company has excellent designers. They understand changing market fashions and trends, so they are able to come up with product ideas based on industry requirements.
3. The culture of red rubber o rings plays a positive role in DMS Seals's development. Get more info! Standing at the new era, DMS Seals will keep promises to clients with our exquisite service with firmer faith. Get more info! buy silicone o rings serves as an impetus to help the realization of DMS Seals' market goal. Get more info! Dms Seals Technology Co.,limited would like to promote the further healthy development of the hydraulic o rings suppliers industry. Get more info! We use 1 inch rubber o ring to connect the future. Get more info!
