hydraulic rod seals hydraulic nbrfkm rod DMS Seal Manufacturer

Standard    Application

Light    Application

Heavy Duty Application

D1    H9

L1+0.2

R1

10MPa

20MPa

40MPa

d2

3-7.9

8-18.9

-

dN+4.9

2.2

0.4

0.3

0.20

0.15

1.78

8-18.9

19-37.9

-

dN+7.3

3.2

0.6

0.4

0.25

0.15

2.62

19-37.9

38-199.9

8-18.9

dN+10.7

4.2

1.0

0.4

0.25

0.20

3.53

38-199.9

200-255.9

19-37.9

dN+15.1

6.3

1.3

0.5

0.30

0.20

5.33

200-225.9

256-649.9

38-199.9

dN+20.5

8.1

1.8

0.6

0.35

0.25

7.00

256-649.9

650-999.9

200-255.9

dN+24.0

8.1

1.8

0.6

0.35

0.25

7.00

650-999.9

≥1000.0

256-649.9

dN+27.3

9.5

2.5

0.7

0.50

0.30

8.40

≥1000.0

-

650-999.9

dN+38.0

13.8

3.0

1.0

0.70

0.60

12.00

Diameter Range

Pressure Range

Temperature Range

Speed

Medium

3-1600mm

0－60MPa

-45℃ +200℃

15 m/s

hydraulic oil, flame retardant liquid,    water, gas

DN h9

D1 H9

L1+0.2

4
5
6

8.9
9.9
10.9

2.2
2.2
2.2

GSI4*8.9*2.2
GSI5*9.9*2.2
GSI6*10.9*2.2

5.6*1.8
6.7*1.8
7.65*1.78

8
8
10

12.9
15.3
14.9

2.2
3.2
2.2

GSI8*12.9*2.2
GSI8*15.3*3.2
GSI10*14.9*2.2

9.5*1.8
10.77*2.62
11.8*1.8

10
12
12

17.3
16.9
19.3

3.2
2.2
3.2

GSI10*17.3*3.2
GSI12*16.9*2.2
GSI12*19.3*3.2

12.37*2.62
14.0*1.78
13.94*2.62

14
14
15

18.9
21.3
19.9

2.2
3.2
2.2

GSI14*18.9*2.2
GSI14*21.3*3.2
GSI15*19.9*2.2

15.6*1.78
17.12*2.62
17.17*1.78

15
16
16

22.3
20.9
23.3

3.2
2.2
3.2

GSI15*22.3*3.2
GSI16*20.9*2.2
GSI16*23.3*3.2

17.12*2.62
17.17*1.78
18.72*2.62

18
18
19

22.9
25.3
29.7

2.2
3.2
4.2

GSI18*22.9*2.2
GSI18*25.3*3.2
GSI19*29.7*4.2

20.35*1.78
20.29*2.62
23.39*3.53

20
20
22

27.3
30.7
29.3

3.2
4.2
3.2

GSI20*27.3*3.2
GSI20*30.7*4.2
GSI22*29.3*3.2

21.89*2.62
25.0*3.53
25.07*2.62

22
24
25

32.7
31.3
32.3

4.2
3.2
3.2

GSI22*32.7*4.2
GSI24*31.3*3.2
GSI25*32.3*3.2

26.57*3.53
26.64*2.62
28.24*2.62

25
26
28

35.7
36.7
35.3

4.2
4.2
3.2

GSI25*35.7*4.2
GSI26*36.7*4.2
GSI28*35.3*3.2

29.74*3.53
29.74*3.53
29.82*2.62

28
30
30

38.7
37.3
40.7

4.2
3.2
4.2

GSI28*38.7*4.2
GSI30*37.3*3.2
GSI30*40.7*4.2

32.92*3.53
32.99*2.62
34.52*3.53

32
32
35

39.3
42.7
42.3

3.2
4.2
3.2

GSI32*39.3*3.2
GSI32*42.7*4.2
GSI35*42.3*3.2

34.59*2.62
36.09*3.53
37.77*2.62

35
36
36

45.7
43.3
46.7

4.2
3.2
4.2

GSI35*45.7*4.2
GSI36*43.3*3.2
GSI36*46.7*4.2

37.69*3.53
39.34*2.62
40.87*3.53

38
38
40

48.7
53.1
50.7

4.2
6.3
4.2

GSI38*48.7*4.2
GSI38*53.1*6.3
GSI40*50.7*4.2

40.87*3.53
43.82*5.33
44.04*3.53

40
42
42

55.1
52.7
57.1

6.3
4.2
6.3

GSI40*55.1*6.3
GSI42*52.7*4.2
GSI42*57.1*6.3

43.82*5.33
47.22*3.53
46.99*5.33

45
45
48

55.7
60.1
58.7

4.2
6.3
4.2

GSI45*55.7*4.2
GSI45*60.1*6.3
GSI48*58.7*4.2

50.39*3.53
50.17*5.33
51.5*3.55

48
50
50

63.1
60.7
65.1

6.3
4.2
6.3

GSI48*63.1*6.3
GSI50*60.7*4.2
GSI50*65.1*6.3

53.34*5.33
53.57*3.53
56.52*5.33

52
52
54

62.7
67.1
69.1

4.2
6.3
6.3

GSI52*62.7*4.2
GSI52*67.1*6.3
GSI54*69.1*6.3

56.74*3.53
56.52*5.33
59.69*5.33

55
55
56

65.7
70.1
66.7

4.2
6.3
4.2

GSI55*65.7*4.2
GSI55*70.1*6.3
GSI56*66.7*4.2

59.92*3.53
59.69*5.33
59.92*3.53

56
58
60

71.1
73.1
70.7

6.3
6.3
4.2

GSI56*71.1*6.3
GSI58*73.1*6.3
GSI60*70.7*4.2

62.87*5.33
62.87*5.33
63.09*3.53

60
63
63

75.1
73.7
78.1

6.3
4.2
6.3

GSI60*75.1*6.3
GSI63*73.7*4.2
GSI63*78.1*6.3

66.04*5.33
66.27*3.53
69.22*5.33

65
67
70

80.1
77.7
80.7

6.3
4.2
4.2

GSI65*80.1*6.3
GSI67*77.7*4.2
GSI70*80.7*4.2

69.22*5.33
72.62*3.53
75.79*3.53

70
72
75

85.1
82.7
85.7

6.3
4.2
4.2

GSI70*85.1*6.3
GSI72*82.7*4.2
GSI75*85.7*4.2

75.57*5.33
75.79*3.53
78.97*3.53

75
80
80

90.1
90.7
95.1

6.3
4.2
6.3

GSI75*90.1*6.3
GSI80*90.7*4.2
GSI80*95.1*6.3

81.92*5.33
85.32*3.53
85.09*5.33

83
85
86

93.7
100.1
96.7

4.2
6.3
4.2

GSI83*93.7*4.2
GSI85*100.1*6.3
GSI86*96.7*4.2

88.49*3.53
91.44*5.33
91.67*3.53

90
90
92

100.7
105.1
102.7

4.2
6.3
4.2

GSI90*100.7*4.2
GSI90*105.1*6.3
GSI92*102.7*4.2

94.84*3.53
94.62*5.33
98.02*3.53

95
95
100

105.7
110.1
110.7

4.2
6.3
4.2

GSI95*105.7*4.2
GSI95*110.1*6.3
GSI100*110.7*4.2

101.19*3.53
100.97*5.33
104.37*3.53

100
105
105

115.1
115.7
120.1

6.3
4.2
6.3

GSI100*115.1*6.3
GSI105*115.7*4.2
GSI105*120.1*6.3

107.32*5.33
110.72*3.53
110.49*5.33
