High-quality hydraulic oil seal manufacturers for pressure work and sliding high speed occasions

Company Advantages
1. DMS Seal Manufacturer hydraulic oil seal manufacturers is well-tailored. It mainly utilizes advanced production machines for sampling, cutting, dyeing, sewing, and performance testing to achieve the best results.
2. DMS Seal Manufacturer goes through a complete manufacturing process. The process includes sourcing fabrics, pattern designing & making, sampling, size grading, review of samples, mass manufacturing, and quality control.
3. The fabric selection of DMS Seal Manufacturer is of high standard. It is based on fabric quality required, like fabric color, fiber content, surface texture, hand feel, and chemical properties.
4. DMS Seal Manufacturer is manufactured under sophisticated processes. The product goes through frame fabricating, extruding, molding, and surface polishing under professional technicians who are experts in furniture making industry.
5. It has a stable sealing effect. The product can work reliably and stably for a long period of time with limited leakage rate.
6. The product is extremely durable. Every single panel is welded with a welded aluminum frame and the internal structure is made of steel mechanism.
7. The product is designed with great electromagnetic compatibility. The insulated housing functions to reduce electromagnetic disturbance to a certain level.
8. The product features an intelligent circuit design. It will stop automatically to protect itself in the case of overload voltage to prevent against the trip.
9. The battery of the product can maintain a charge abundant enough to supply electricity at night or in the absence of sunlight.
10. The possible flaws in production and on-time delivery of product quality and quantity are ensured in Dms Seals Technology Co.,limited.
11. The price we made for our hydraulic oil seal manufacturers is reasonable.
12. With excellent engineering technology and high-quality hydraulic oil seal manufacturers , Dms Seals Technology Co.,limited has won unanimous recognition from customers.
13. Both the quality of hydraulic oil seal manufacturers and customer service play an important role in DMS Seal Manufacturer.

1. Installation Recommendation

2. Application and properties

The standard combination seal is suitable for a wide range of pressure work and sliding high speed occasions. Low friction, strong wear resistance.

3. Standard materials

Sealing ring: filled PTFE

O-Ring: NBR / FKM

4. Working Conditions

Working  Conditions
Diameter Range	Pressure Range	Temperature Range	Speed	Medium
3 - 1600mm	0 - 35MPa	-30℃ +200℃	1.5 m/s	general hydraulic oil, water glycol Hydraulic oil and water emulsion type hydraulic oil.

5. Installation Dimensions

Nominal Size of Packing, and Housing dimensions				Order No.
d	D	H	L +0.2
3 4 5	6 7 8	2.3 2.3 2.3	2.5 2.5 2.5	SPNC3*6*2.5 SPNC4*7*2.5 SPNC5*8*2.5
6 7 8	9 10 11	2.3 2.3 2.3	2.5 2.5 2.5	SPNC6*9*2.5 SPNC7*10*2.5 SPNC8*11*2.5
9 10 10	12 13 14	2.3 2.3 3.0	2.5 2.5 3.2	SPNC9*12*2.5 SPNC10*13*2.5 SPNC10*14*3.2
11 11.2 12	15 15.2 16	3.0 3.0 3.0	3.2 3.2 3.2	SPNC11*15*3.2 SPNC11.2*15.2*3.2 SPNC12*16*3.2
12.5 14 15	16.5 18 19	3.0 3.0 3.0	3.2 3.2 3.2	SPNC12.5*16.5*3.2 SPNC14*18*3.2 SPNC15*19*3.2
16 18 20	20 22 24	3.0 3.0 3.0	3.2 3.2 3.2	SPNC16*20*3.2 SPNC18*22*3.2 SPNC20*24*3.2
20 21 22	24 25 26	3.0 3.0 3.0	3.2 3.2 3.2	SPNC20*24*3.2 SPNC21*25*3.2 SPNC22*26*3.2
22 22.4 24	28 28.4 30	4.4 4.4 4.4	4.7 4.7 4.7	SPNC22*28*4.7 SPNC22.4*28.4*4.7 SPNC24*30*4.7
25 25.5 26	31 31.5 32	4.4 4.4 4.4	4.7 4.7 4.7	SPNC25*31*4.7 SPNC25.5*31.5*4.7 SPNC26*32*4.7
28 29 29.5	34 35 35.5	4.4 4.4 4.4	4.7 4.7 4.7	SPNC28*34*4.7 SPNC29*35*4.7 SPNC29.5*35.5*4.7
30 31 31.5	36 37 37.5	4.4 4.4 4.4	4.7 4.7 4.7	SPNC30*36*4.7 SPNC31*37*4.7 SPNC31.5*37.5*4.7
32 34 35	38 40 41	4.4 4.4 4.4	4.7 4.7 4.7	SPNC32*38*4.7 SPNC34*40*4.7 SPNC35*41*4.7
35.5 36 38	41.5 42 44	4.4 4.4 4.4	4.7 4.7 4.7	SPNC35.5*41.5*4.7 SPNC36*42*4.7 SPNC38*44*4.7

Company Features
1. Known as globally famous manufacturer, Dms Seals Technology Co.,limited primarily deals with hydraulic oil seal manufacturers . Widely known as a highly advanced enterprise, Dms Seals Technology Co.,limited has been focusing on innovation of metric wiper seals . Dms Seals Technology Co.,limited is a technologically advanced company in the field of forklift hydraulic cylinder seals .
2. Dms Seals Technology Co.,limited has introduced sizable set of hydraulic seals pdf manufacturing machines. If ignoring the importance of technology optimization, hallite hydraulic seals could not have been so popular in the market. The coordinated development of technology development and research will ensure the quality of hydraulic rod wipers . DMS Seal Manufacturer's factory has a variety of advanced professional production equipment and testing equipment.
3. Our company bears social responsibilities. With our environmental programs, measures are taken together with our customers to actively conserve resources and reduce carbon dioxide emissions in the long term. We bear social responsibilities. As a result, we use high quality recycled or natural materials in the vast majority of our products. Safety is our top priority. We aim to sustain the highest standards of product, process, and occupational safety throughout our whole business.
