DMS Seals premier seals manufacturing cost

Company Advantages
1. Our premier seals manufacturing touches softly and smoothly.
2. The remarkable merits of material for premier seals manufacturing are durable and beautiful.
3. premier seals manufacturing is proved practically feasible in structure and could be worthy of recommendation.
4. The product features an intelligent circuit design. It will stop automatically to protect itself in the case of overload voltage to prevent against the trip.
5. The product won't easily absorb liquids. It will not stain from spills, such as coffee, tea, wine, or fruit juice.
6. This garment lasts well. It has sturdy and durable fabric which is woven in a manner that it can be effortlessly worn for a long time.
7. It has the good soundproof capability. Its heart board part is made of premium timber such as extrusion chipboard or designed with a bee structure, all which can effectively keep out the sound.
8. Except for adopting superior material, premier seals manufacturing is produced on sophisticated equipment.
9. Dms Seals Technology Co.,limited's products are all 100% guaranteed by high quality foreign brands.
10. 'Mutual care and mutual achievement' are the principles that Dms Seals Technology Co.,limited has been adhering to the company's internal interaction with customers.
11. Dms Seals Technology Co.,limited has obtained much achievement in premier seals manufacturing area.

1. Installation Recommendation

2. Installation Sizes

Rod Diameter	Outer Diameter	Groove Width	Install Chamfer	Radius	Radial Clearance                S max.
d f8	D H8	L+0.2	L1	R1	10MPa	20MPa	40MPa
50-69.9	d+15.0	7.5	5.0	0.4	0.5	0.4	0.3
70-149.9	d+20.0	10.1	6.0	0.4	0.7	0.5	0.4
200-244.9	d+25.0	12.5	8.5	0.4	0.8	0.6	0.5
245-519.9	d+30.0	15.0	10.0	0.8	0.9	0.7	0.6
520-769.9	d+35.0	17.5	13.0	1.2	1.0	0.8	0.7
770-1500	d+40.0	20.0	15.0	1.2	1.0	0.8	0.7

3. Application and properties

Applied for larger diameter piston rods and heavy-duty hydraulic rod sealing system in hard working conditions. High pressure resistance, excellent resistance to gap extrusion, wear-resisting.

4. Standard materials

Sealing ring: filled PTFE

O-Ring: NBR / FKM



5. Working Conditions

Working  Conditions
Diameter Range	Pressure Range	Temperature Range	Speed	Medium
3 - 1600mm	0 - 60MPa	-30℃ +100℃	5 m/s	hydraulic oil, flame retardant liquid, water, gas

6. Installation Dimensions

Rod Dia.	Outer Dia.	Groove Width	Order No.
d f8	D H8	L+0.2
50 60 70	65 75 85	7.5 7.5 7.5	GSJ-W50*65*7.5 GSJ-W60*75*7.5 GSJ-W70*85*7.5
75 80 100	95 100 120	10 10 10	GSJ-W75*95*10 GSJ-W80*100*10 GSJ-W100*120*10
110 115 120	130 135 140	10 10 10	GSJ-W110*130*10 GSJ-W115*135*10 GSJ-W120*140*10
130 140 145	150 160 165	10 10 10	GSJ-W130*150*10 GSJ-W140*160*10 GSJ-W145*165*10
150 160 170	170 180 190	10 10 10	GSJ-W150*170*10 GSJ-W160*180*10 GSJ-W170*190*10
175 180 200	195 200 220	10 10 10	GSJ-W175*195*10 GSJ-W180*200*10 GSJ-W200*220*10
230 240 250	255 265 275	12.5 12.5 12.5	GSJ-W230*255*12.5 GSJ-W240*265*12.5 GSJ-W250*275*12.5
260 265 270	285 290 295	12.5 12.5 12.5	GSJ-W260*285*12.5 GSJ-W265*290*12.5 GSJ-W270*295*12.5
280 290 300	305 315 325	12.5 12.5 12.5	GSJ-W280*305*12.5 GSJ-W290*315*12.5 GSJ-W300*325*12.5

Company Features
1. Dms Seals Technology Co.,limited is proud of its exceptional record of producing a series of premier seals manufacturing in such an efficient way. As a large manufacturer of brake seals suppliers , Dms Seals Technology Co.,limited have a wide range of overseas markets. Dms Seals Technology Co.,limited has several production lines to perform the mass production of hydraulic rubber seal . Dms Seals Technology Co.,limited has gained world-wide popularity because of oil seal manufacturers china .
2. After years of dedication to improving product quality, we have been selected as a business partner by many famous brands. This is strong proof of our ability in this field. After many years of solid development, our company has grown into a sizable factory. There have been established complete production lines in the factory, including parts distribution lines, dust-free treatment lines, and final assembly lines. This proofs that the factory has achieved standardization production. At present, the company’s production scale and market share have been soaring up in the foreign market. Most of our products have been sold to many countries around the world. This shows our sale volumes keep on increasing. Our manufacturing team consists of experienced specialists. Every day, they produce high-quality products with great sensitivity, both as standard and as custom solutions.
3. As a magic weapon to inspire DMS Seals to overcome difficulties and continue to advance, our corporate culture is metric mechanical seals . Contact! To supply the best split oil seal manufacturer for customers, DMS Seals aim to do the utmost to achieve the goal. Contact! Dms Seals Technology Co.,limited insists on taking as the direction of business development. Contact! Dms Seals Technology Co.,limited suggests as its everlasting pursuit. Contact! DMS Seals aims to be a complete one-stop products supplier. Contact!
