DMS Seals 3 roller bearing wear ring for sale

Company Advantages
1. It is widely accepted that our 3 roller bearing is well designed from raw materials.
2. The main structure of the 3 roller bearing is composed of which is applicable in many occasions.
3. Various 3 roller bearing provided by Dms Seals Technology Co.,limited has reasonable structure and reliable quality.
4. The production of 3 roller bearing always take into account.
5. Made from high-quality , 3 roller bearing has been the best selling product in DMS Seals.
6. This product is chemically resistant. The use of neutral materials greatly avoids changes in the quality characteristics of the product itself due to the surrounding chemical environment.
7. The product has a large storage capacity. The materials used have a huge reversible capacity and active chemicals used have a high volume.
8. The product is chemically stable. It is not subject to aging under high temperature nor corroding in the organic solvent.
9. The product ensures prolonged seal performance in high-temperature applications. It will not lose its physical integrity, and its performance will not diminish quickly in such environments.
10. The product is anti-bacterial. The antimicrobial agent is added to improve the cleanliness of the surface, preventing the growth of bacteria.
11. With strong capital and independent R&D team, Dms Seals Technology Co.,limited is a dynamic and innovative team.
12. Dms Seals Technology Co.,limited has comprehensively deepened its Internet marketing strategy.
13. Dms Seals Technology Co.,limited's working team features high quality, responsible and innovative.

1. Installation Recommendation

2. Application and properties

Applicable to the guiding of piston and piston rod of hydraulic cylinder and air cylinder, has the function of supporting and guiding. The guide strips with the thickness which equal to or greater than 2mm, double sided embossing could be provided, the embossing structure is conducive to the formation of lubrication micro-pit, improve micro lubrication, at the same time, it is helpful to embed tiny foreign objects and protect the sealing system.

3. Standard materials

White virgin PTFE

4. Working Conditions

Working  Conditions
Diameter Range	Pressure Range	Temperature Range	Speed	Medium
Custom as Required	—	-55℃ +225℃	15 m/s	hydraulic oil, emulsion, and water

Piston:  L=C × ( D - W ) - k [ mm ] D = Piston Dia. [ mm ] W = Thickness [ mm ]

Rod:    L=C × ( d + W ) - k [ mm ] d = Rod Dia. [ mm ]  C = 3.14  k=0.8

5. Length of whole roll

Thickness	1	1.5	2	2.5	3	4	5	6
Length of whole roll ( m )	55	35	27	22	18	13	10	8

Above data only for reference, it shall follow the actual products.

Standard groove width

Groove width L2

2.5

3.2

4

4.2

5.6

6

6.3

8.1

9.7

10

12

15

18

20

25

30

40

50

The products of various width could be provided.

Standard thickness of product

Thickness W

1

1.5

1.55

2

2.5

3

4

5

6

The products of various thickness could be provided.

Company Features
1. Dms Seals Technology Co.,limited is an integrated supplier that provides consumers with comprehensive products and 3 roller bearing services. Dms Seals Technology Co.,limited has achieved rapid development in the tapered bearing race industry. Our DMS Seals lead the industry and quality is superior.
2. DMS Seals has been introducing technology to involve in the process of bearing manufacturing machine production. By utilizing new technology, DMS Seals produces rubber seal manufacturers that brings newly high technology experience to customers. Fully implementing technical research helps DMS Seals become a leading tapered roller bearing manufacturers supplier.
3. Dms Seals Technology Co.,limited sincerely hopes our ball bearing types and applications can bring great value to our customers. Get an offer! Dms Seals Technology Co.,limited inherits the culture of . Get an offer! By clinging to the business philosophy of , Dms Seals Technology Co.,limited achieves great success. Get an offer! Dms Seals Technology Co.,limited's goal is to gradually develop from a small industry to a large industry. Get an offer!
