DMS Seal Manufacturer viton rubber seal with nbr or fkm o ring to high and low speed

Company Advantages
1. The design of DMS Seal Manufacturer viton rubber seal caters to the foreign markets.
2. Unique and stylish design for viton rubber seal is definitely a positive factor.
3. viton rubber seal is brightly colorful and .
4. Each production phase of DMS Seal Manufacturer is strictly supervised.
5. DMS Seal Manufacturer is an innovation-oriented product with improvement on production process.
6. No matter which bedding the users desire, they can rest easy knowing this product will be hypo-allergenic, anti-bacterial, and waterproof.
7. This product does not contain harmful substances. During the production phase, the yarns used to create the fabric are not chemically treated.
8. The product has good heat dissipation. Usually constructed from composite metal materials which have a very high thermal conductivity, it features a high rate of heat transfer.
9. The product has overload protection. It has a thermal relay which can withstand the impact of short circuit due to thermal inertia.
10. The product has won good user reputation and has great market application prospects.
11. The product has a great future in this realm because of its remarkable economic return.
12. This product can well meet the application needs of customers.
13. The product has been widely used in the global market due to its high economic return.
14. The product is available at very competitive prices and is widely used in the market.

1. Installation Recommendation

2. Installation Sizes

d e8	D H9	L D10	H
22-39	d+7.2	4.0	3.5
40-79	d+10.0	5.0	4.5
80-100	d+13.8	7.5	7.0
＞100-250	d+20.0	10.0	9.5
＞250-600	d+30.0	15.0	14.5
＞600	d+40.0	20.0	19.5

3. Application and properties

L-Ring support and guide to ensure a tight sealing environment. Easy installation, wear resistance, anti extrusion, low friction, non stick slip phenomenon.



4. Standard materials

Sealing ring: filled PTFE

O-Ring: NBR / FKM

L-Ring: POM / PA

5. Working Conditions

Working  Conditions
Diameter Range	Pressure Range	Temperature Range	Speed	Medium
3 - 1600mm	0 - 45MPa	-30℃ +100℃	1 m/s	hydraulic oil, flame retardant liquid, water, gas

6. Installation Dimensions

d e8	D1 H9	H	L D10	e	Order No.
22 25 28	29.2 32.2 35.2	3.5 3.5 3.5	4 4 4	6 6 6	RDI22*29.2*3.5 RDI25*32.2*3.5 RDI28*35.2*3.5
30 32 35	37.2 39.2 42.2	3.5 3.5 3.5	4 4 4	6 6 6	RDI30*37.2*3.5 RDI32*39.2*3.5 RDI35*42.2*3.5
36 40 42	43.2 50 52	3.5 4.5 4.5	4 5 5	6 6 6	RDI36*43.2*3.5 RDI40*50*4.5 RDI42*52*4.5
45 50 55	55 60 65	4.5 4.5 4.5	5 5 5	6 6 6	RDI45*55*4.5 RDI50*60*4.5 RDI55*65*4.5
56 60 63	66 70 73	4.5 4.5 4.5	5 5 7.5	6 7 7	RDI56*66*4.5 RDI60*70*4.5 RDI63*73*4.5
65 70 72	75 80 82	4.5 4.5 4.5	7.5 7.5 7.5	7 7 7	RDI65*75*4.5 RDI70*80*4.5 RDI72*82*4.5
75 80 85	85 93.8 98.8	4.5 7.0 7.0	7.5 7.5 7.5	7 7 7	RDI75*85*4.5 RDI80*93.8*7.0 RDI85*98.8*7.0
90 95 100	103.8 108.8 113.8	7.0 7.0 7.0	7.5 7.5 7.5	7 7 7	RDI90*103.8*7.0 RDI95*108.8*7.0 RDI100*113.8*7.0
105 110 115	125 130 135	9.5 9.5 9.5	10 10 10	10 10 10	RDI105*125*9.5 RDI110*130*9.5 RDI115*135*9.5
120 125 130	140 145 150	9.5 9.5 9.5	10 10 10	10 10 10	RDI120*140*9.5 RDI125*145*9.5 RDI130*150*9.5

Company Features
1. Since the establishment, Dms Seals Technology Co.,limited has accumulated many years of experience in the design and manufacturing of . Dms Seals Technology Co.,limited is a dynamic and fast-moving company specializing in manufacturing . We have proven that we are one of the market leaders in China. Dms Seals Technology Co.,limited has grown from a local manufacturer in China to a trusted international manufacturer in the production of . Dms Seals Technology Co.,limited has become an expert in manufacturing . Over the years, we have been engaged in development and production. Dms Seals Technology Co.,limited has been engaged in production for many years, and now it has become a leading Dms Seals Technology Co.,limited production enterprise in China.
2. The cutting-edge technology adopted in viton rubber seal helps us win more and more customers. Almost all technician talent for the industry of hydraulic rod seals work in our Dms Seals Technology Co.,limited. All our technical staff are rich in experience for kit seal cylinder .
3. Stressing hydraulic pump oil seal could be a more effective way to help DMS Seal Manufacturer win high comments from customers at home and abroad. Ask online! Dms Seals Technology Co.,limited strives to reduce and simplify management processes to achieve optimized efficiency. Ask online! Our unrelenting pursuit is . Ask online!

DMS Seal Manufacturer viton rubber seal with nbr or fkm o ring to high and low speed

viton rubber seal

Type:
