DMS Seal Manufacturer o-ring seal with nbr or fkm o ring for sale1

Company Advantages
1. The necessary tests for DMS Seal Manufacturer piston rod seal have been finished. These tests cover colorfastness testing, rub fastness testing, dimensional stability testing, and abrasion resistance testing. Our products mainly include rod seals, piston seals, scraper seals, rotary seals, rubber seal products and spring seals
2. To meet the requirements of our customers all over the world, we have equipped o-ring seal with advanced production lines and experienced technicians. DMS Seals' production equipment and test equipment are on the leading level in the industry
3. This product has good resistance to flexure. It will be not subjected to continuous flexing in walking or running and remains intact during the exercise. The R&D teams have the ability to design and develop seals for various of complicated working condition of sealing system
4. The product is resistant to corrosion. It has the ability to resist the impact of chemical acids, strong cleaning fluids or hydrochloric compounds. We can support OEM and ODM

1. Installation Recommendation

2. Application and properties

The standard combination seal is suitable for a wide range of pressure work and sliding high speed occasions. Low friction, strong wear resistance.

3. Standard materials

Sealing ring: filled PTFE

O-Ring: NBR / FKM

4. Working Conditions

Working  Conditions
Diameter Range	Pressure Range	Temperature Range	Speed	Medium
3 - 1600mm	0 - 35MPa	-30℃ +200℃	1.5 m/s	general hydraulic oil, water glycol Hydraulic oil and water emulsion type hydraulic oil.

5. Installation Dimensions

Nominal Size of Packing, and Housing dimensions				Order No.
d	D	H	L +0.2
3 4 5	6 7 8	2.3 2.3 2.3	2.5 2.5 2.5	SPNC3*6*2.5 SPNC4*7*2.5 SPNC5*8*2.5
6 7 8	9 10 11	2.3 2.3 2.3	2.5 2.5 2.5	SPNC6*9*2.5 SPNC7*10*2.5 SPNC8*11*2.5
9 10 10	12 13 14	2.3 2.3 3.0	2.5 2.5 3.2	SPNC9*12*2.5 SPNC10*13*2.5 SPNC10*14*3.2
11 11.2 12	15 15.2 16	3.0 3.0 3.0	3.2 3.2 3.2	SPNC11*15*3.2 SPNC11.2*15.2*3.2 SPNC12*16*3.2
12.5 14 15	16.5 18 19	3.0 3.0 3.0	3.2 3.2 3.2	SPNC12.5*16.5*3.2 SPNC14*18*3.2 SPNC15*19*3.2
16 18 20	20 22 24	3.0 3.0 3.0	3.2 3.2 3.2	SPNC16*20*3.2 SPNC18*22*3.2 SPNC20*24*3.2
20 21 22	24 25 26	3.0 3.0 3.0	3.2 3.2 3.2	SPNC20*24*3.2 SPNC21*25*3.2 SPNC22*26*3.2
22 22.4 24	28 28.4 30	4.4 4.4 4.4	4.7 4.7 4.7	SPNC22*28*4.7 SPNC22.4*28.4*4.7 SPNC24*30*4.7
25 25.5 26	31 31.5 32	4.4 4.4 4.4	4.7 4.7 4.7	SPNC25*31*4.7 SPNC25.5*31.5*4.7 SPNC26*32*4.7
28 29 29.5	34 35 35.5	4.4 4.4 4.4	4.7 4.7 4.7	SPNC28*34*4.7 SPNC29*35*4.7 SPNC29.5*35.5*4.7
30 31 31.5	36 37 37.5	4.4 4.4 4.4	4.7 4.7 4.7	SPNC30*36*4.7 SPNC31*37*4.7 SPNC31.5*37.5*4.7
32 34 35	38 40 41	4.4 4.4 4.4	4.7 4.7 4.7	SPNC32*38*4.7 SPNC34*40*4.7 SPNC35*41*4.7
35.5 36 38	41.5 42 44	4.4 4.4 4.4	4.7 4.7 4.7	SPNC35.5*41.5*4.7 SPNC36*42*4.7 SPNC38*44*4.7

Company Features
1. Dms Seals Technology Co.,limited serves as pioneer in the field of o-ring seal by providing all kinds of products. Dms Seals Technology Co.,limited puts lots of money and energy on improving quality of hydraulic rod seals .
2. Dms Seals Technology Co.,limited has introduced many advanced machines used in the production of O Ring Manufacturers .
3. DMS Seal Manufacturer is established mainly because of its strong influence in quality. Dms Seals Technology Co.,limited will strive to enhance its competitive advantage through continuous innovation on rod seals . Please contact.
