DMS Seal Manufacturer large o ring assortment manufacturers for static sealing

Company Advantages
1. The well-developed series of large o ring assortment products produced by Dms Seals Technology Co.,limited's excellent R&D teams are naturally favored by consumers.
2. In terms of design, large o ring assortment extracts the essence of simplicity.
3. DMS Seal Manufacturer adopts standard and safe production process.
4. It will not consume extra energy. The certification provided by the Environmental Protection Agency is considered the most authentic in this regard, and the Energy Star label is the mark of this certification.
5. The product will not eliminate the healthy elements out, such as magnesium, zinc, iodine, etc. Because the super nano separation technology used can eliminate the harmful substances out yet retain the healthy elements.
6. This product has excellent vibration resistance. It is not affected by the vibration, deflection or other movements of the rotating shaft.
7. It can be regarded as a green source of energy. All of its metal ingredients, including cadmium and mercury, as well as the electrolyte, poses no harm to the environment.
8. The biggest advantage of this product is energy saving. It is able to make self-adjustment to meet usage requirements while consuming little energy.
9. The product has a wider and wider market thanks to its above advantages.
10. This product is widely used in various applications and has great market potential.
11. This product has great economic benefits and is very popular among customers.
12. The product is widely recognized by our clients, showing the great market potential.

1. Installation Recommendation

2. Application and properties

Double acting seals, the sealing effect is achieved by the deformation of the section of the O-Rings, and the deformation is determined by the depth of the installation groove. Under pressure, the O-ring has a large surface tension like liquid, used for static sealing more. It is only recommended for better conditions in dynamic applications. System lubrication, pressure, temperature, sealing clearance, speed, medium and surface quality of metal parts determine the service life of O-Rings. It is not recommended if the lubrication is not sufficient during rotary motion.

3. Standard materials

Silicone

4. Performance parameter

	Static Seal	Dynamic Seal
Working Pressure	No support ring, up to 20MPa; With the support ring, up to 40MPa; With special support ring, up to 200MPa.	No support ring, up to 5MPa; With the support ring, higher pressure.
Movement Speed	Maximum reciprocating speed up to 0.5m / s; maximum rotation speed up to 2.0m/s.
Temperature	NBR: -30℃ - 100℃;  FKM: -20℃ - 220℃.

5. Wire Diameter Tolerance

Wire diameter of O-Ring (mm)	Tolerance (±mm)
0-1.8	0.08
1.80-2.65	0.09
2.65-3.55	0.10
3.55-5.30	0.13
5.30-7.00	0.15
7.00-8.00	0.18
8.00-10.00	0.21
10.00-12.00	0.25



6. Inner diameter tolerance

Inner Diameter d1 mm	Tolerance ±mm	Inner Diameter d1 mm	Tolerance ±mm	Inner Diameter d1 mm	Tolerance ±mm
0.70-2.50 2.50-4.50 4.50-6.30	0.13 0.14 0.15	43.70-45.00 46.00-46.20 46.20-47.50	0.42 0.43 0.44	95.00-97.50 97.50-100.00 100.00-103.00	0.83 0.84 0.87
6.30-8.50 8.50-10.00 10.00-11.20	0.16 0.17 0.18	47.50-48.70 48.70-50.00 50.00-51.50	0.45 0.46 0.47	103.00-106.00 106.00-109.00 109.00-112.00	0.89 0.91 0.93
11.20-14.00 14.00-16.00 16.00-18.00	0.19 0.20 0.21	51.50-53.00 53.00-54.50 54.50-56.00	0.48 0.50 0.51	112.00-115.00 115.00-118.00 118.00-122.00	0.95 0.97 1.00
18.00-20.00 20.00-21.20 21.20-23.60	0.22 0.23 0.24	56.00-58.00 58.00-60.00 60.00-61.50	0.52 0.54 0.55	122.00-125.00 125.00-128.00 128.00-132.00	1.03 1.05 1.08
23.60-25.00 25.00-26.50 26.50-28.00	0.25 0.26 0.28	61.50-63.00 63.00-65.00 65.00-67.00	0.56 0.58 0.59	132.00-136.00 136.00-140.00 140.00-145-00	1.10 1.13 1.17
28.00-30.00 30.00-31.50 31.50-33.50	0.29 0.31 0.32	67.00-69.00 69.00-71.00 71.00-73.00	0.61 0.63 0.64	145.00-150.00 150.00-155.00 155.00-160.00	1.20 1.24 1.27
33.50-34.50 34.50-35.50 35.50-36.50	0.33 0.34 0.35	73.00-75.00 75.00-77.50 77.50-80.00	0.66 0.67 0.69	160.00-165.00 165.00-170.00 170.00-175.00	1.31 1.34 1.38
36.50-37.50 37.50-38.70 38.70-40.00	0.36 0.37 0.38	80.00-82.50 82.50-85.00 85.00-87.50	0.71 0.73 0.75	175.00-180.00 180.00-185.00 185.00-190.00	1.41 1.44 1.48
40.00-41.20 41.20-42.50 42.50-43.70	0.39 0.40 0.41	87.50-90.00 90.00-92.50 92.50-95.00	0.77 0.79 0.81	190.00-195.00 195.00-200.00 200.00-206.00	1.51 1.55 1.59
206.00-212.00 212.00-218.00 224.00-230.00	1.63 1.71 1.75	325.00-335.00 335.00-345.00 345.00-355.00	2.43 2.49 2.56	500.00-515.00 515.00-530.00 530.00-545.00	3.54 3.63 3.72
230.00-236.00 236.00-243.00 243.00-250.00	1.79 1.83 1.88	355.00-365.00 365.00-375.00 375.00-387.00	2.62 2.68 2.76	545.00-560.00 560.00-580.00 580.00-600.00	3.81 3.93 4.05
250.00-258.00 258.00-265.00 265.00-272.00	1.93 1.98 2.02	387.00-400.00 400.00-412.00 412.00-425.00	2.84 2.91 2.99	600.00-615.00 615.00-630.00 630.00-650.00	4.13 4.22 4.34
272.00-280.00 280.00-290.00 290.00-300.00	2.08 2.14 2.21	425.00-437.00 437.00-450.00 450.00-462.00	3.07 3.15 3.22	650.00-670.00	4.46
300.00-307.00 307.00-315.00 315.00-325.00	2.25 2.30 2.37	462.00-475.00 475.00-485.00 485.00-500.00	3.30 3.37 3.45

Company Features
1. With so many years, Dms Seals Technology Co.,limited has been specializing in the R&D, design, and manufacture of . We have become a famous manufacturer in the industry. With extensive experience and expertise, Dms Seals Technology Co.,limited provides the manufacturing power needed to create the world's best . After years of dedication to large o ring assortment production, Dms Seals Technology Co.,limited has already become an expert with competence in R&D and manufacture. Dms Seals Technology Co.,limited has set foot in the development, design, and manufacture of o rubber ring years ago. We have gained market recognition over the years.
2. Our factory is constantly invested in a series of manufacturing facilities. With the help of these advanced facilities, they enable us to improve overall operational efficiency for our manufacturing projects. We have an excellent R&D team. It consists of technical experts such as product developers and computer scientists. They can design great products. We have imported a series of state-of-the-art manufacturing facilities. These facilities constantly underwent routine inspections and are maintained in good conditions. This will greatly support our whole production process. We have a large export share in recent years and our sales volume in overseas markets keeps increasing at a record rate. This mainly thanks to the ever increasing customer base overseas. The company has been recognized with the International Quality Management System. This system offers clients an assurance of our products' traceability and production quality.
3. DMS Seal Manufacturer has great ambition to win the main market of rubber ring supplier . Ask! DMS Seal Manufacturer may make a welcome contribution to customers' business growth. Ask! As a provider, our aim is to deliver our high quality merchandise into the international sector. Ask! Dms Seals Technology Co.,limited seek commonality in R&D while preserving differences with customers. Ask!
