DMS Seal Manufacturer hydraulic piston seals manufacturer for pneumatic equipment2

Company Advantages
1. With a team of highly specialized designer, our DMS Seal Manufacturerhydraulic piston seals is given an aesthetic appearance design.
2. DMS Seal Manufacturer rubber piston seals is manufactured as per the set industry standards.
3. DMS Seal Manufacturer hydraulic piston seals is manufactured by using the high precision equipment and the latest technology.
4. Stability is one of its advantages. It can run under rigorous conditions such as extreme weather conditions or sudden blackout.
5. This product is equipped with protective qualities thanks to the coatings. While the coating is in liquid form, chemical compounds are added to provide pigment, flame retardance, UV, water and mildew resistance.
6. The product is wear and tear resistant. Its materials are all abrasion-proof and have excellent chemical and physical strength and stiffness.
7. The amount of light being reflected from its surface is always sufficient. Its surface is generally coated with barium sulfate or titanium dioxide accompanied by magnesium carbonate.
8. This product is breathable. It utilizes a waterproof and breathable fabric layer that acts as a barrier against dirt, moisture, and bacteria.
9. The product would better cater to different market needs, leading to a more promising market application prospect.
10. The driving force of this product's development comes from the huge market demand in the industry.
11. DMS Seal Manufacturer has gone far ahead in the hydraulic piston seals industry for the finest quality service.

1. Installation Recommendation

2. Application and properties

Extreme wear resistance, easy installation on single-part piston without assembly aids due to the split design of the sealing ring. Assembly on one-part piston is possible. Insensitive to extreme pressure peaks. Extreme high extreme pressure resistance. High pressure an large gaps due to the special compound properties of the seal ring. Dimensions according to ISO 7425-1. Short axial assembly length. Installation in closed and undercut housings. Additional sizes of machined products available on short notice.

3. Standard materials

Sealing ring: filled modified thermoplast

O-ring: NBR

4. Working Conditions

Working  Conditions
Diameter Range	Pressure Range	Temperature Range	Speed
25 - 480mm	0 - 80MPa	-30℃ +110℃	≤1 m/s

5. Installation Dimensions

D1	d1	L	Order No.
25 32 40	16 21 26.3	4.2 4.2 5.8	OK25*16*4.2 OK32*21*4.2 OK40*26.3*5.8
40 50 50	29 34.5 36.3	4.2 6.3 5.8	OK40*29*4.2 OK50*34.5*6.3 OK50*36.3*5.8
50 50 55	37 39 44	8 4.2 4.2	OK50*37*8 OK50*39*4.2 OK55*44*4.2
55 60 60	44 41.7 49	4.2 7 4.2	OK55*44*4.2 OK60*41.7*7 OK60*49*4.2
63 63 63	44.7 47.5 52	7 6.3 4.2	OK63*44.7*7 OK63*47.5*6.3 OK63*52*4.2
70 70 70	51.7 54.5 54.5	7 6.3 6.3	OK70*51.7*7 OK70*54.5*6.3 OK70*54.5*6.3
70 75 75	59 54 59.5	4.2 8 6.3	OK70*59*4.2 OK75*54*8 OK75*59.5*6.3
80 80 85	59 64.5 64	8 6.3 8	OK80*59*8 OK80*64.5*6.3 OK85*64*8
90 90 95	69 74.5 74	8 6.3 8	OK90*69*8 OK90*74.5*6.3 OK95*74*8
100 100 105	79 84.5 84	8 6.3 8	OK100*79*8 OK100*84.5*6.3 OK105*84*8
110 110 115	89 94.5 94	8 6.3 8	OK110*89*8 OK110*94.5*6.3 OK115*94*8
115 120 125	100 99 104	8 8 8	OK115*100*8 OK120*99*8 OK125*104*8
125 130 130	109.5 109 114.5	6.3 8 6.3	OK125*109.5*6.3 OK130*109*8 OK130*114.5*6.3
130 135 135	115 114 119.5	8 8 6.3	OK130*115*8 OK135*114*8 OK135*119.5*6.3
140 140 145	119 125 124	8 8 8	OK140*119*8 OK140*125*8 OK145*124*8
150 150 152.4	129 135 131.5	8 8 8	OK150*129*8 OK150*135*8 OK152.4*131.5*8
160 160 165	139 148 144	8 8 8	OK160*139*8 OK160*148*8 OK165*144*8
170 175 180	149 154 159	8 8 8	OK170*149*8 OK175*154*8 OK180*159*8
190 200 210	169 179 189	8 8 8	OK190*169*8 OK200*179*8 OK210*189*8
220 220 230	199 205 209	8 8 8	OK220*199*8 OK220*205*8 OK230*209*8
240 250 260	225 229 239	8 8 8	OK240*225*8 OK250*229*8 OK260*239*8
270 280 290	249 255.5 271	8 8 9.5	OK270*249*8 OK280*255.5*8 OK290*271*9.5
300 320 330	272 292 302	9.5 9.5 9.5	OK300*272*9.5 OK320*292*9.5 OK330*302*9.5
350 370 420	322 342 392	9.5 9.5 9.5	OK350*322*9.5 OK370*342*9.5 OK420*392*9.5
450 480	422 452	9.5 9.5	OK450*422*9.5 OK480*452*9.5

Company Features
1. Dms Seals Technology Co.,limited is a manufacturer that specializes in the design and manufacture of rubber piston seals. We have the best knowledge base and highly acclaimed customer service. Dms Seals Technology Co.,limited has been operating for many years and has been considered a reliable manufacturing factory for hydraulic cylinder piston seals . With its successful marketing strategies, Dms Seals Technology Co.,limited is winning more market shares both at home and abroad in the industry of hydraulic piston seals sizes .
2. We have a factory. Being equipped with advanced machinery and technology, it can make our products better - more competitive, unique, robust and reliable. We have our self-established testing engineers. They play a significant role in the performance and function of our products. By using their abundant expertise, they can iron out bugs and improve the quality of the finished products. Our company has teams of experts. The members hold expertise in their field of specialization and assist the company to produce products as per the instructions of our customers.
3. We have forced sustainability practices into every aspect of our business. For example, we reduce greenhouse gas emissions and minimize production waste. We believe that sustainability is important for our business. We reduce greenhouse gas emissions and design our products to minimize waste. These important actions are factored into every aspect of our business. We conserve water across a wide range of actions, extending from recycling water and installing new technologies to upgrading water treatment plants. We’re passionate about caring for our clients' business as if it were our own. Our clients' needs are our top priority, and we strive to provide the most effective and economical solutions for them.

DMS Seal Manufacturer hydraulic piston seals manufacturer for pneumatic equipment

hydraulic piston seals

Type:
