DMS Seal Manufacturer hydraulic cylinder seal kits factory for sale

Company Advantages
1. DMS Seal Manufacturer is subject to a diverse range of tests and assessments. It is checked against furniture functionality, sizes, stability, balance, space for feet, etc.
2. Sophisticated manufacturing techs are used in DMS Seal Manufacturer . The product is done under the support of 2D/3D and CAD design techs, CAM machining tech, Gait balance analysis tech, and so on.
3. DMS Seal Manufacturer will be analyzed with regard to different facets. It will proceed with an examination for its colorfastness, dimensions, materials safety, solvents' ingredients, bacteria resistance, odor, etc.
4. DMS Seal Manufacturer has been strictly monitored during production. It has been inspected with regards to cracks, discoloration, structural safety, slip resistance, and biomechanical comfort.
5. This product stands out for its durability. With a specially coated surface, it is not prone to oxidation with seasonal changes in humidity.
6. This product has the required durability. It is made with the right materials and construction and can withstand objects dropped on it, spills, and human traffic.
7. The product has good chemical properties. It has been pre-treated to stand up the corrosive condition, such as chemical liquid environment.
8. It is not prone to burn out due to excessive temperatures. It is designed with a temperature protection system to prevents internal components.
9. Users will enjoy a better night off realizing that this product will not cause skin problems and leaves an amazing touch to the skin.
10. The offered product is valued for their huge benefits like compatibility and usability.
11. It has accumulated a large number of consumer groups, domestic and foreign brand resources.
12. The product shows great value in the industry and is bound to meet the specific requirements of customers.
13. The product is provided as per the precise needs of the customers in the market.

1. Installation Recommendation

2. Installation Sizes

Rod Diameter d e8	Groove Diameter D H9	Groove Width L D10	H
20-30	d+8	7.5	7
31-35	d+8	7.5	7
36-44	d+8	8.5	8
45-55	d+10	11.0	10
56-119	d+15	13.0	12
120-319	d+20	17.0	16
320-499	d+30	21.0	20
＞499	d+40	26.5	25

3. Application and properties

Applicable to hydraulic cylinder piston rod, generally used in conjunction with the guide sleeve. The special-shaped Y-Ring has the sealing function, provides the elasticity to the seal ring, and compensates for the abrasion. Wear-resisting, non stick slip phenomenon. It has a high stability under pressure and harsh conditions.

4. Standard materials

Sealing ring: filled PTFE

Y-Ring: NBR / PU

5. Working Conditions

Working  Conditions
Diameter Range	Pressure Range	Temperature Range	Speed	Medium
3 - 1600mm	0 - 60MPa	-30℃ +100℃	1 m/s	Petroleum base hydraulic oil, nonflammable hydraulic fluid, water, and others.

6. Installation Dimensions

Rod Dia.	Outer Dia.	Groove Width	Order No.
d e8	D H9	L D10
20 22 23	28 30 31	7.5 7.5 7.5	TDI20*28*7.5 TDI22*30*7.5 TDI23*31*7.5
25 28 30	33 36 38	7.5 7.5 7.5	TDI25*33*7.5 TDI28*36*7.5 TDI30*38*7.5
32 35 36	40 43 44	7.5 7.5 8.5	TDI32*40*7.5 TDI35*43*7.5 TDI36*44*8.5
40 42 45	48 50 55	8.5 8.5 11	TDI40*48*8.5 TDI42*50*8.5 TDI45*55*11
47 48 50	57 58 60	11 11 11	TDI47*57*11 TDI48*58*11 TDI50*60*11
52 55 56	62 65 71	11 11 13	TDI52*62*11 TDI55*65*11 TDI56*71*13
60 63 65	75 78 80	13 13 13	TDI60*75*13 TDI63*78*13 TDI65*80*13
68 70 72	78 85 87	13 13 13	TDI68*78*13 TDI70*85*13 TDI72*87*13
75 80 83	90 95 98	13 13 13	TDI75*90*13 TDI80*95*13 TDI83*98*13

Company Features
1. Our hydraulic cylinder seal kits are produced by our advanced technology and well-equipped facilities. There are many positive feedback from customers for our case hydraulic seal kits . Processed by high quality materials, our exquisite pneumatic cylinder rod seal owns different design styles with high quality.
2. DMS Seal Manufacturer has a complete buy hydraulic seals production laboratory. Our DMS Seal Manufacturer is far ahead in the piston seal field. In order to become one of the most influential companies, DMS Seal Manufacturer has been committed to producing rod seal installation with high quality. DMS Seal Manufacturer introduces highly sophisticated technology to ensure the quality of pneumatic seal kit . Dms Seals Technology Co.,limited owns professional team of experienced curtain wall production and processing engineers and designers
3. Part of the strength of our company comes from talented people. Though already being recognized as experts in the field, they never stop learning through lectures at conferences and events. They allow the company to provide exceptional service. Our goal is to acquire new customers from innovative offerings. This objective makes us always focus on the innovation ahead of market trends. Get an offer! The customer service from DMS Seal Manufacturer will ensure that our customers receive the best products through our professional philosophy. Get an offer! We have stepped up seriously into practicing sustainable development. We have strived to reduce waste and carbon footprint during production, and we also recycle packaging materials for reuse. We are committed to providing the highest level of manufacturing services to customers by building strong customer relationships and leading the evolution in this industry. Get an offer!

DMS Seal Manufacturer hydraulic cylinder seal kits factory for sale

hydraulic cylinder seal kits

Type:
